Rectangular grey control box with front panel labels and cable entries

FRANKLIN

FRANKLIN 2824085015 Control Box 1HP 230V 1Phase

SKU CH-MP6G-4W36W MPN 2824085015

A 1 HP, 230 V single-phase control box identified by part number 558832 with Franklin Electric QD relay for pump operation

  • TypeDrain Components
  • 1 HP motor rating delivers strong pumping performance
  • 230 V single-phase input suits standard residential power
  • Exclusive Franklin Electric QD relay protects the pump motor
  • Designed for drain and trap installations
  • Proposition 65 warning notes chemical content awareness

Franklin 1 HP 230 V Control Box

This Franklin Electric control box is built for single-phase submersible pump installations rated at 1 horsepower and 230 volts. It houses the exclusive QD relay that manages motor starting and running sequences. The unit is intended for residential and light-commercial water systems that require reliable pump control. Installers and property owners use it to replace worn or damaged panels on existing 1 HP pumps.

Replaces Failed 1 HP Pump Panels

The box serves as a direct swap for a malfunctioning control panel on a 1 HP, 230 V, single-phase submersible pump. Upgrading is worthwhile when the original relay shows chatter, overheating or voltage irregularities that trip breakers. It restores proper start and run capacitor switching without rewiring the motor. Do not use it on pumps with different horsepower or voltage ratings.

Verify Pump Rating and Wiring Before Ordering

Confirm the motor nameplate states 1 HP, 230 V and single-phase operation to match this control box. Check that the existing conduit, wire gauge and breaker size suit the panel's terminal layout. Ensure local codes permit the installation and that the mounting location provides adequate ventilation. The product carries a California Proposition 65 warning for chemicals known to cause cancer and reproductive harm.

Highlights

  • 1 HP motor rating delivers strong pumping performance
  • 230 V single-phase input suits standard residential power
  • Exclusive Franklin Electric QD relay protects the pump motor
  • Designed for drain and trap installations
  • Proposition 65 warning notes chemical content awareness

Specifications

TypeDrain Components
BrandFranklin
Model2824085015

Questions about this item

What voltage and phase rating does the Franklin 2824085015 control box require for installation?

The control box is rated for 230 V single-phase power, matching the 1 HP motor specification.

Which relay is included inside the Franklin 2824085015, and how should it be wired during setup?

The box ships with an exclusive Franklin Electric QD relay; follow the supplied wiring diagram to connect line, motor and ground leads in the correct sequence.

Does the Franklin 2824085015 control box contain any components that trigger California Proposition 65 warnings?

Yes, the product contains a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
