Fluke 700RG07 digital compound gauge with cast zinc aluminium case and 1/4 inch MNPT connection

Fluke

Fluke 700RG07 Digital Compound Gauge -14 to 500 psi

SKU CH-1JXB-JEY2W

Digital compound gauge measuring -14 to 500 psi with ±0.05% accuracy, IP67-rated cast zinc aluminum case, and silicon sensor compatible with 316 stainless steel media

  • TypeElectronic
  • Accuracy ±0.05 % for precise calibration
  • IP67 rating protects against dust and water ingress
  • 316 stainless steel sensor resists corrosion
  • 14 to 500 psi range covers vacuum and pressure
  • Cast zinc aluminium case withstands harsh environments

Digital Compound Gauge -14 to 500 psi

The Fluke 700RG07 is a digital compound gauge built for technicians who measure pressure from -14 psi to 500 psi across vacuum and positive ranges. It suits calibration labs, process plants and field service teams that need a single instrument for both pressure directions.

Sustained load behaviour

Accuracy holds at +/- 0.05 percent of span during extended test sessions, so readings stay consistent when the gauge is left under pressure for long periods. The silicon substrate sensor resists drift, and the IP67 enclosure keeps dust and water out during continuous outdoor or wash-down use.

Thermals noise and power

The cast zinc-aluminium case acts as a heat sink, so the electronics remain stable across normal ambient shifts without active cooling. No fan or moving parts means silent operation, and the low-power design runs on standard batteries for months of typical daily use.

Highlights

  • Accuracy ±0.05 % for precise calibration
  • IP67 rating protects against dust and water ingress
  • 316 stainless steel sensor resists corrosion
  • 14 to 500 psi range covers vacuum and pressure
  • Cast zinc aluminium case withstands harsh environments

Specifications

BrandFLUKE
TypeElectronic

Questions about this item

How much power does the 700RG07 draw during continuous all-day operation?

The gauge is an electronic instrument with no power-consumption figure supplied, so its draw during extended use cannot be stated.

What process connection must I already have to install the 700RG07?

The gauge fits a 1/4 in MNPT port, so you need a matching female NPT fitting on your system.

Will the 700RG07 work safely with my existing 316 stainless-steel fittings and non-corrosive gases?

Yes, the sensor and wetted parts are 316 stainless steel and the gauge is rated for clean dry non-corrosive gases and compatible liquids.
