Red Festo flat cylinder DZF-12-80-A-P-A in box

Festo

Festo DZF-12-80-A-P-A 161228 Flat Cylinder electrician tool

SKU CH-C2XP-AJ5RY MPN DZF-12-80-A-P-A

Flat cylinder with 12 mm bore and 80 mm stroke for pneumatic test equipment

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact flat cylinder fits tight spaces
  • 12 mm bore delivers precise linear force
  • 80 mm stroke covers required travel range
  • New condition ensures full factory performance
  • Part number 161228 simplifies ordering and maintenance

Flat cylinder for pneumatic systems

The Festo DZF-12-80-A-P-A is a compact flat cylinder designed for linear motion in automated machinery. Its guided piston rod prevents rotation and resists side loads without external guide units. The unit suits installation where space is limited and precise, repeatable strokes are required. Supplied new in a single pack under part number 161228.

Engineers needing anti-rotation in tight spaces

This cylinder fits designers who must eliminate rod rotation in confined layouts such as pick-and-place arms or clamping fixtures. It does not suit applications that demand long stroke lengths beyond the 80 mm travel or high-speed cycling that exceeds the standard pneumatic cushioning range. Buyers who need integrated position sensing should verify sensor-slot compatibility before ordering.

80 mm stroke length

The defining specification is the 80 mm stroke combined with the 12 mm bore diameter, which together set the working envelope and force output. Matching these two figures to the machine layout confirms whether the cylinder reaches the required end positions and delivers sufficient thrust at the available supply pressure. No other dimension in the data sheet overrides this pair for selection.

Highlights

  • Compact flat cylinder fits tight spaces
  • 12 mm bore delivers precise linear force
  • 80 mm stroke covers required travel range
  • New condition ensures full factory performance
  • Part number 161228 simplifies ordering and maintenance

Specifications

BrandFESTO
ModelDZF-12-80-A-P-A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How is the Festo DZF-12-80-A-P-A flat cylinder mounted, and which alignment step is often missed?

Mount the cylinder using the standard flat-profile fixing holes on the 12 mm bore body; the step often missed is ensuring the piston rod centreline stays parallel to the guide rails so the 80 mm stroke runs without side load.

What maintenance will the DZF-12-80-A-P-A need after extended cycles?

Plan to replace the piston seals and rod wiper after high cycle counts; the manufacturer notes a three-year parts coverage period for these wear items.

What limit appears first when the cylinder runs continuously at full 80 mm stroke?

Heat build-up in the compact flat body limits sustained rapid cycling; allow cooling intervals to avoid seal degradation.
