A silver metal USB Type-A female connector with a threaded nut, shown disassembled with top and bottom covers lying flat

Fervit

Fervit USB 3.0 Type-A Female Receptacle Solder 6.0mm Cable

SKU CH-A87T-E5KWK

A USB 3.0 Type-A female receptacle with aluminum alloy shell for soldering onto 6.0mm cable, supporting Super-Speed 5Gbps, Hi-Speed 480Mbps and Low-Speed 1.5Mbps

  • USB 3.0 Super-Speed 5Gbps for fast data transfer
  • Backward compatible with USB 2.0 480Mbps and USB 1.1 1.5Mbps
  • Solder-type connector enables DIY cable customisation
  • Aluminium alloy shell protects the plug for reliable performance
  • Designed for 6.0mm OD USB 3.0 cable assemblies

USB 3.0 Type-A Female Receptacle

This Fervit connector is a solder-type USB 3.0 Type-A female receptacle designed for custom cable assemblies. It accepts cables with a 6.0 mm outer diameter and includes an aluminium alloy shell, top cover, bottom cover and screw nut. The component is sold new and requires the user to solder wires directly to the contacts.

DIY builders and OEM integrators

Suits engineers, hobbyists and OEM/ODM projects that need a bespoke USB 3.0 Type-A connection on a 6.0 mm cable. Not for buyers who want a ready-made cable with moulded ends or a connector that crimps or screws onto wires without soldering. Also unsuitable for designs that require a different cable diameter or a male plug format.

Solder-type termination for 6.0 mm cable

The single deciding specification is the solder-type termination matched to a 6.0 mm outer-diameter cable. If your build uses a different cable size or demands a crimp, IDC or press-fit termination, this receptacle will not work. The aluminium shell and included hardware support the soldered assembly once the correct cable is chosen.

Highlights

  • USB 3.0 Super-Speed 5Gbps for fast data transfer
  • Backward compatible with USB 2.0 480Mbps and USB 1.1 1.5Mbps
  • Solder-type connector enables DIY cable customisation
  • Aluminium alloy shell protects the plug for reliable performance
  • Designed for 6.0mm OD USB 3.0 cable assemblies

Specifications

BrandFervit

Questions about this item

Will this USB 3.0 Type-A receptacle work with my older USB 2.0 and 1.1 devices?

Yes, it supports USB 3.0 Super-Speed at 5Gbps, USB 2.0 Hi-Speed at 480Mbps and USB 1.1 Low-Speed at 1.5Mbps.

How can I verify the receptacle is functioning correctly after I solder my 6.0mm cable?

Plug a known USB 3.0 device into the finished connector and confirm the host detects it at Super-Speed 5Gbps; the aluminum alloy shell also ensures solid contact.

What components come in the box and what must I supply myself?

The package includes the connector, top cover, bottom cover and screw nut; you must provide a 6.0mm OD USB 3.0 cable and a soldering iron.
