Fervit USB 3.0 left-angled male-to-female panel cable 30cm

Fervit

Fervit USB 3.0 Left-Angled Male to Female Panel Cable 30cm

SKU CH-2NAQ-CNS8X

A 30 cm left-angled USB 3.0 panel cable with 90-degree male-to-female Type-A connectors and 30 mm screw-hole spacing for tight-fit installations

  • Left-angled connector fits tight spaces around USB ports
  • 30 cm cable length with 30 mm screw-hole spacing for panel mounting
  • USB 3.0 SuperSpeed 5 Gbps throughput for fast data transfers
  • Backward compatible with USB 2.0 and USB 1.1 devices
  • Single-piece moulded construction built for durability

USB 3.0 panel cable for tight spaces

This left-angled Type-A male-to-female cable extends a USB 3.0 header by 30 cm. The 90-degree connector lets you plug devices into ports that sit close to case walls or other components. It supports keyboards, mice, flash drives, external drives, printers, hubs, SSDs and cameras. The cable is rated for USB 3.0 Super-Speed at 5 Gbps and remains backward compatible with USB 2.0 and 1.1.

Installation and common issues

The panel mount uses two screw holes spaced 30 mm apart, so verify that your chassis cut-out matches this pitch before fitting. Route the short 30 cm tail carefully; excess tension on the angled plug can stress the header pins. The single-piece moulded strain relief resists accidental pulls, but the fixed length offers no slack for repositioning once secured.

Practical limits of the USB 3.0 interface

Maximum signalling rate is 5 Gbps, with automatic fallback to 480 Mbps for USB 2.0 devices and 1.5 Mbps for USB 1.1 peripherals. The 30 cm cable length is well within the USB 3.0 specification, so signal integrity is not a concern. Bandwidth is shared among all devices connected through the same host controller, so simultaneous high-throughput transfers will reduce per-device throughput. Not suited for builders who need longer internal runs or right-angled orientation on the device side.

Highlights

  • Left-angled connector fits tight spaces around USB ports
  • 30 cm cable length with 30 mm screw-hole spacing for panel mounting
  • USB 3.0 SuperSpeed 5 Gbps throughput for fast data transfers
  • Backward compatible with USB 2.0 and USB 1.1 devices
  • Single-piece moulded construction built for durability

Specifications

BrandFervit

Questions about this item

How can I confirm the cable is running at USB 3.0 5Gbps after installation?

Connect a USB 3.0 flash drive or SSD and check the operating system reports a SuperSpeed connection; transfer speeds should approach the 5Gbps link rate.

What comes with the cable and do I need separate mounting screws?

The 30cm left-angled Type-A male-to-female panel cable is supplied as a single unit; mounting screws for the 30mm hole spacing are not included.

Which version should I choose for a USB 3.0 panel header?

This model is a USB 3.0 Type-A panel cable with a 90-degree left-angled connector, 30cm length and 30mm screw-hole spacing — select it when those exact specifications match your chassis cut-out.
