Black internal USB 2.0 splitter cable with four 9-pin female ports and IDE power connector

Fervit

Fervit USB 2.0 9pin 10pin Header 1 to 4 Female Splitter Extension Cable HUB with IDE 5V Power Connector

SKU CH-YKY8-Q7MRV

Splits one motherboard USB 2.0 9-pin header into four 9-pin connectors and adds an IDE 5 V power input with adhesive backing for internal mounting

  • Connect four 9-pin USB devices from one header
  • Extra 5 V power via IDE 4-pin connector
  • Adhesive backing secures cable to board or chassis
  • Extends a single 9-pin header to four ports
  • Supports USB 2.0 internal connections

Internal USB 2.0 header expander

This splitter cable turns a single motherboard 9-pin USB 2.0 header into four female 9-pin ports. It is designed for builders who need to connect multiple internal USB devices such as card readers, front-panel hubs or lighting controllers without adding a separate controller card.

Four ports with optional 5 V auxiliary power

The board provides four 9-pin connectors that share the host header’s bandwidth, so throughput is limited to the USB 2.0 specification. An IDE 4-pin power connector is included to supply extra 5 V current when the combined draw of attached devices exceeds what the motherboard header can deliver.

Glue-back mounting for tight chassis

A self-adhesive backing lets the hub stick directly to the motherboard tray or chassis wall, keeping cables tidy in small cases. Builders who require more than four internal USB connections or need USB 3.0 speeds will need a different solution.

Highlights

  • Connect four 9-pin USB devices from one header
  • Extra 5 V power via IDE 4-pin connector
  • Adhesive backing secures cable to board or chassis
  • Extends a single 9-pin header to four ports
  • Supports USB 2.0 internal connections

Specifications

BrandFervit

Questions about this item

Will this splitter work with the USB 2.0 9-pin header on my older motherboard?

Yes, the cable connects to a motherboard USB 2.0 9-pin header and provides four 9-pin female ports for internal devices.

How can I confirm the splitter is delivering power to all four ports after installation?

Connect the IDE 4-pin power connector to a 5 V supply from the PSU; each attached USB device should then enumerate in the OS.

Does the package include the IDE power cable or must I buy it separately?

The IDE 4-pin power connector is built into the splitter, so no separate power cable is required.
