Small green circuit board with M.2 2230 male edge connector and vertical OCuLink SFF-8612 female port

Fervit

Fervit M.2 2230 M-Key to OCuLink SFF-8612 Adapter

SKU CH-RP32-QBTVS

Adds an OCuLink SFF-8612 port to a 2230 M-Key slot for NVME SSD or eGPU use at PCIe 4.0 speeds

  • Connects an NVMe SSD or eGPU via optional cable
  • Transmits PCI Express 4.0 signals using NVMe protocol
  • Provides 64Gbps bandwidth with NVMe 1.2 support
  • Expands a 2230 M-Key slot to an OCuLink SFF-8612 interface
  • Features 67-pin M.2 Key M male and SFF-8612 female connectors

Fervit M.2 2230 M-Key Adapter

This new Fervit adapter converts an M.2 2230 M-Key slot into an OCuLink SFF-8612 interface. It allows users to connect an NVMe SSD or an eGPU graphics card via an optional cable. The card transmits PCI Express 4.0 signals using the NVME protocol. It expands the system by one SFF-8612 OCuLink port for external devices.

Sustained Signal Integrity

The adapter maintains PCI Express 4.0 signal quality over the OCuLink SFF-8612 link during continuous data transfers. It supports the NVM Express 1.2 specification for consistent NVME storage performance. The vertical host design provides a direct connection path without active components. This passive layout avoids thermal throttling under prolonged workloads.

64Gbps Data Rate Limit

The single specification that decides suitability is the maximum data transfer rate of 64Gbps. This bandwidth ceiling defines the peak throughput for any attached NVME drive or eGPU. Builders requiring higher bandwidth must select a different interconnect solution. The 67-pin M.2 Key M male connector mates directly with the host slot.

Highlights

  • Connects an NVMe SSD or eGPU via optional cable
  • Transmits PCI Express 4.0 signals using NVMe protocol
  • Provides 64Gbps bandwidth with NVMe 1.2 support
  • Expands a 2230 M-Key slot to an OCuLink SFF-8612 interface
  • Features 67-pin M.2 Key M male and SFF-8612 female connectors

Specifications

BrandFervit

Questions about this item

Does the adapter add fan noise or heat when an NVMe drive runs continuously?

The board is a passive signal converter with no active cooling, so it adds no fan noise and negligible heat beyond the drive itself.

What cable do I need to connect an NVMe U.2 SSD or eGPU to the OCuLink SFF-8612 port?

An OCuLink SFF-8612 to SFF-8611 or U.2 cable is required; the adapter only provides the female SFF-8612 receptacle.

Will a PCIe 3.0 M.2 2230 slot still work with this PCIe 4.0 adapter?

Yes, the adapter is backward compatible and will operate at PCIe 3.0 speeds when installed in a PCIe 3.0 M.2 Key M slot.
