Rectangular dual NVME M-key enclosure with built-in fan and USB-C cable

Fervit

Fervit Dual NVME M-Key Enclosure 20Gbps with Fan

SKU CH-1QRF-XDHA6

Dual M-key NVME enclosure with built-in fan, 20Gbps USB-C 3.1 Gen 2, RAID 0/1/JBOD/BIG, up to 2x 2TB

  • Active cooling protects drives during heavy workloads
  • RAID 1 mirrors data for automatic redundancy
  • RAID 0 combines drives for maximum throughput
  • JBOD mode presents each SSD as an independent volume
  • USB-C 3.1 Gen 2 delivers 20Gbps bandwidth with UASP support

Dual NVME M-Key Enclosure with Active Cooling

This Fervit enclosure houses two M-key NVME SSDs in lengths from 2230 to 2280 mm. It connects via a USB-C 3.1 Gen 2 link rated at 20 Gbps and includes a built-in RPM fan to move heat away from both drives. The unit supports Windows 7, 8, 10 and 11 plus Mac OS 10.11 and above.

RAID Mode Selection Determines Capacity

Choose RAID 0 for combined speed and capacity, RAID 1 for mirroring, JBOD for two independent volumes, or BIG for a single spanned volume. Each mode changes how the host sees the storage, so pick the one that matches the workload before inserting the drives.

Tool-Free Drive Bays with a Cable Length Caveat

Drives slide into the bays without screws and the USB Type C to C cable is supplied in the box. The enclosure needs a host port that can deliver enough current for two SSDs plus the fan; some tablets or phones only work when OTG is enabled and may require an external power source.

Highlights

  • Active cooling protects drives during heavy workloads
  • RAID 1 mirrors data for automatic redundancy
  • RAID 0 combines drives for maximum throughput
  • JBOD mode presents each SSD as an independent volume
  • USB-C 3.1 Gen 2 delivers 20Gbps bandwidth with UASP support

Specifications

BrandFervit

Questions about this item

What real-world throughput does the 20Gbps USB-C 3.1 Gen 2 link deliver inside a PC?

The 20Gbps interface caps at the host controller speed, so actual NVME SSD transfer rates will be limited by the USB-C 3.1 Gen 2 bandwidth and UASP overhead.

Which USB standard does the 20Gbps port implement and what does it limit?

It uses USB-C 3.1 Gen 2 at 20Gbps, which sets the maximum data rate for both RAID 0 and JBOD configurations.

What physical SSD sizes and mounting does the enclosure accept?

It fits 2230, 2242, 2260 and 2280 M-key NVME SSDs, up to two drives of 2TB each, secured in the fan-cooled chassis.
