Silver rackmount network switch with sixteen RJ45 ports and two SFP+ uplinks

Extreme Networks

Extreme Networks 5320-16P-2MXT-2X 16-port PoE network switch

SKU CH-25KW-94YB9 MPN 5320-16P-2MXT-2X

A managed rackmount switch with 16 PoE ports at 30W each, 180W total budget, and 2 SFP+ uplinks for 10Gb fibre

  • FormatRackmount
  • Network Management TypeManaged
  • Primary Ports16 x RJ45 + 2 x SFP+
  • Management InterfaceInterfaces: 16 x 10/100/1000BASE-T 802.3at (30W) ports Full
  • MAC Address TableMAC Table (without Fabric enabled): 32,000 MAC Table (with F
  • IPv4 FeaturesIPv4 Route Table: 1,000

Model 5320-16P-2MXT-2X

  • 16 PoE ports deliver 30W each for powered devices
  • 180W total PoE budget supports multiple access points and cameras
  • Fanless design ensures silent operation in office environments
  • 2 x 10Gb SFP+ uplinks provide high-speed backbone connectivity
  • Managed switch with 32,000 MAC entries for scalable network segmentation

16-port managed PoE switch

The Extreme Networks 5320-16P-2MXT-2X is a rackmount managed switch with sixteen 10/100/1000BASE-T ports supporting 802.3at PoE at 30W each. It includes two 1/2.5/5/10GBase-T uplinks and two 10Gb SFP+ uplinks for aggregation. The unit operates without fans and draws up to 218W total power. It suits network teams needing quiet, high-density access switching with cloud or on-premise management options.

180W PoE budget and dual uplinks

A 180W PoE budget powers the sixteen downlink ports for phones, cameras or access points without external injectors. The two multi-rate copper uplinks and two SFP+ cages give flexibility for fibre or copper uplinks up to 10Gb. Dual USB and console ports simplify initial setup and ongoing maintenance. Fabric-enabled MAC capacity is 16,000 entries; without Fabric it rises to 32,000.

Quiet rack deployments needing 16 PoE ports

This model fits environments where silent operation and a single 180W PoE pool are required. It does not suit buyers who need a larger PoE budget for more high-power devices, or teams requiring higher uplink density than two 10Gb SFP+ ports. The IPv4 route table holds 1,000 entries, limiting use in large Layer 3 cores.

Highlights

  • 16 PoE ports deliver 30W each for powered devices
  • 180W total PoE budget supports multiple access points and cameras
  • Fanless design ensures silent operation in office environments
  • 2 x 10Gb SFP+ uplinks provide high-speed backbone connectivity
  • Managed switch with 32,000 MAC entries for scalable network segmentation

Specifications

BrandExtreme Networks
Series5320 Series
Model5320-16P-2MXT-2X
Part Number5320-16P-2MXT-2X
FormatRackmount
Network Management TypeManaged
Primary Ports16 x RJ45 + 2 x SFP+
Management InterfaceInterfaces:
16 x 10/100/1000BASE-T 802.3at (30W) ports
Full / Half-Duplex (autosensing)
2 x 1/2.5/5/10GBase-T uplink ports
2 x 10Gb SFP+ uplink ports
Fanless model
1 x Serial console port (RJ-45)
1 x USB A ports for management or external USB flash
1 x USB-C console port
MAC Address TableMAC Table (without Fabric enabled): 32,000
MAC Table (with Fabric enabled): 16,000
IPv4 FeaturesIPv4 Route Table: 1,000
PoEYes
PoE Ports16 x PoE
PoE Power Budget180W
Max Power Consumption218W
Shipping weight4.31 kg
Package size381 × 254 × 127 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the internal fan on the 5320-16P-2MXT-2X ever need cleaning or replacement?

The switch is a fanless model with no moving parts, so there is no fan to clean or replace during its service life.

Which limit is reached first when all sixteen PoE ports run at 30 W continuously?

The 180 W PoE budget caps total output, so only six ports can deliver 30 W at once before the budget is exhausted.

How much heat does the 5320-16P-2MXT-2X add to a rack when operating at full load all day?

Maximum power draw is 218 W, which converts directly into heat inside the rack under sustained full-load operation.
