Evertech USA 8MP HD-CVI AHD TVI Analog Passive Video Audio Power Balun Transmitter (8 Pairs)

Passive video audio power balun kit

This kit contains eight pairs of passive baluns that transmit video, audio and DC power over UTP cable. Each unit uses gold-plated BNC connectors and an ABS plastic housing for reliable contact. The transceivers support AHD, TVI, CVI and analog CVBS formats up to 8MP resolution. Installers can run a single Cat5e or Cat6 cable to carry all three signals between camera and recorder.

Suits multi-camera UTP runs not for IP networks

The baluns suit installers upgrading analog or HD-over-coax systems to structured cabling without active gear. They cover distances up to 200 m for 8MP signals and 300 m for standard definition. Buyers who need IP camera integration or PoE power delivery should choose a different product class. The passive design also means no external power supply is required at the camera end.

Transmission distance by resolution

Maximum reach depends on the video format: 8MP to 1080p AHD, TVI or CVI signals travel 200 m (656 ft); 960p and 720p signals reach 250 m (820 ft); analog CVBS and 960H extend to 300 m (1,000 ft). Selecting the correct cable category and resolution ensures the link stays within these limits.
