Rectangular lithium battery pack, blue label, 47.8 by 34.2 by 17.4 mm

Estry

Estry A06B-6093-K001 standard battery 6.0V 2200mAh

SKU CH-JJZB-K143Y MPN A06B-6093-K001

6.0 V 2200 mAh lithium replacement battery for GE and Fanuc models A06B-6093-K001 and A98L-0031-0011/L

  • TypeBatteries
  • Battery Pack1-pack
  • Battery TypeLithium
  • Battery Capacity2200mAh
  • Battery Voltage6
  • Replaces GE A06B-6093-K001 and Fanuc A98L-0031-0011/L models
  • Lithium chemistry delivers 6.0V and 2200mAh capacity
  • Built-in overcharge, over-discharge, over-voltage and short-circuit protection
  • Certified to ISO9001, RoHS, CE, UN38.3 and MSDS standards
  • Compact 47.8 x 34.2 x 17.4 mm size weighs 73.0g

Direct replacement for Fanuc A98L-0031-0011/L

This lithium battery pack matches the original GE A06B-6093-K001 specifications. It fits Fanuc A98L-0031-0011/L and BR-AGCF2W part numbers. The unit ships new and carries ISO9001, RoHS, CE, UN38.3 and MSDS certifications.

Capacity and runtime headroom

Rated at 6.0V and 2200mAh, the cell stores 13.2Wh of energy. It powers compatible control modules through a full shift under normal loads. Runtime shortens when the module draws peak current continuously or operates in high-temperature environments.

Thermal behaviour and power draw

Lithium chemistry keeps self-discharge low and voltage stable during discharge. The pack includes over-charge, over-discharge, over-voltage and short-circuit protection circuits. No active cooling is required; the 73.0g housing stays at ambient temperature in typical cabinet installations.

Highlights

  • Replaces GE A06B-6093-K001 and Fanuc A98L-0031-0011/L models
  • Lithium chemistry delivers 6.0V and 2200mAh capacity
  • Built-in overcharge, over-discharge, over-voltage and short-circuit protection
  • Certified to ISO9001, RoHS, CE, UN38.3 and MSDS standards
  • Compact 47.8 x 34.2 x 17.4 mm size weighs 73.0g

Specifications

BrandGE
TypeBatteries
Battery Pack1-pack
Battery TypeLithium
Battery Capacity2200mAh
Battery Voltage6

Questions about this item

Will the 47.8 x 34.2 x 17.4 mm dimensions fit the original battery compartment in my Fanuc A98L-0031-0011/L unit?

The replacement matches the original form factor at 47.8 x 34.2 x 17.4 mm and weighs 73.0 g, so it seats directly in the Fanuc A98L-0031-0011/L compartment without modification.

How can I verify the 6.0 V 2200 mAh pack is delivering the rated 13.2 Wh after installation?

Measure the pack voltage with a multimeter; a healthy cell reads near 6.0 V under no load. Then monitor the equipment run-time — it should match the original 13.2 Wh capacity.

Does the single 1-pack include the BR-AGCF2W connector lead or must I order it separately?

The 1-pack supplies the complete 6.0 V 2200 mAh lithium cell with the BR-AGCF2W connector already fitted; no extra cable or adapter is required.
