Rectangular Ni-MH battery pack with dark casing and label, 134.82 x 33.9 x 31.62mm

Estry

Estry 199C 7.2V 3600mAh Ni-MH standard battery

SKU CH-854X-00RF2 MPN 199C

Replacement Ni-MH battery pack delivers 7.2 V and 3600 mAh for Fluke 199C, 196B, 196C, 199B, 192B, 433, 434, 435 and 190M analysers

  • Specifications7.2
  • Battery Pack1 Year
  • Exact-fit replacement for Fluke 199C, 196B and 190-series analysers
  • 2 V 3600 mAh Ni-MH chemistry delivers 25.92 Wh runtime
  • Built-in overcharge, over-discharge, over-voltage and short-circuit protection
  • ISO 9001, RoHS, CE and UN 38.3 certified for safety and quality
  • Compact 134.82 x 33.9 x 31.62 mm pack weighs 352.7 g

Direct replacement for Fluke analysers

The Estry 199C is a 7.2 V 3600 mAh nickel-metal hydride pack built to match the original specifications for Fluke 199C, 196B, 199, 190M, 199B, 192, 192B, 196, 196C, 433, 434 and 435 analysers and oscilloscopes. It delivers 25.92 Wh of capacity and includes overcharge, over-discharge, over-voltage and short-circuit protection for safe operation.

Verify model and part number before ordering

Check that your instrument appears in the supported list — 199C, 196B, 199, 190M, 199B, 192, 192B, 196, 196C, 433, 434 or 435 — and that the original battery part number is B11432, BP190, 677390 or BP-190. The pack measures 134.82 x 33.9 x 31.62 mm and weighs 352.7 g, so confirm the battery compartment can accept those dimensions.

Certified cells with protective circuitry

Each cell is tested to ISO 9001, RoHS, CE, UN 38.3 and MSDS standards and carries a one-year battery-pack warranty from the manufacturer. The integrated protection board guards against common fault conditions, while the standard form factor allows a straight swap without soldering or adapter cables.

Highlights

  • Exact-fit replacement for Fluke 199C, 196B and 190-series analysers
  • 2 V 3600 mAh Ni-MH chemistry delivers 25.92 Wh runtime
  • Built-in overcharge, over-discharge, over-voltage and short-circuit protection
  • ISO 9001, RoHS, CE and UN 38.3 certified for safety and quality
  • Compact 134.82 x 33.9 x 31.62 mm pack weighs 352.7 g

Specifications

BrandNi-MH
Model3000mAh
Specifications7.2
Battery Pack1 Year

Questions about this item

What comes in the box and do I need any extra cables or chargers?

The package contains the Estry 199C Ni-MH battery pack only; it fits directly into the listed Fluke analysers and scopes, so no additional cables or chargers are required.

Which capacity version should I pick for my Fluke 199C oscilloscope?

This replacement is rated at 3600 mAh and 7.2 V (25.92 Wh), matching the original BP-190 specification for the 199C and other compatible models.

How long will a 3600 mAh 7.2 V pack run my Fluke 199C in the field?

The 25.92 Wh capacity typically provides several hours of continuous operation on a Fluke 199C or 196 series ScopeMeter, depending on backlight and measurement load.
