Small black rectangular capture dongle with HDMI and USB ports

ESTONE

ESTONE OZC1 4K HDMI to USB Video Capturing Device 1080p60

SKU CH-225M-H07WW

Captures 4K HDMI input at 60 Hz and outputs 1080p60 via USB 2.0 for streaming with OBS, VLC or Amcap on Windows, Mac or Linux

  • InterfaceUSB 2.0
  • FormatYUV / JPEG; Support audio format: L-PCM
  • Resolution Support1080P
  • Camera ResolutionUp to 1080p Video
  • ColorBlack
  • HDMI1 In
  • Capture 4K input at 60 Hz for crisp source footage
  • Record or stream at 1080p 60 fps for smooth output
  • Plug-and-play on Windows, Mac and Linux with no drivers needed
  • Works with OBS, VLC, Amcap and other popular capture software
  • Compact 64 × 28 × 13 mm design weighs only 21.4 g

Capture purpose

The Estone OZC1 captures HDMI video and audio from cameras or consoles and delivers it to a computer over USB 2.0. It accepts 4K input at 60 Hz and outputs up to 1080p at 60 Hz for recording or streaming. The device works with Windows, macOS and Linux without proprietary drivers.

Build integration

A single HDMI source connects to the input while the USB 2.0 link carries the captured stream to the host. The compact 64 x 28 x 13 mm body draws 0.4 A at 5 V from the USB port, so no external power supply is required. Standard AWG26 HDMI cables up to 15 metres are supported for 1080p signals.

Buyer fit

Streamers and educators who need simple 1080p60 capture from a DSLR, camcorder or game console will find this unit straightforward. Users requiring 4K60 output, higher-bitrate codecs or multi-channel audio beyond L-PCM should consider a capture device with those specifications.

Highlights

  • Capture 4K input at 60 Hz for crisp source footage
  • Record or stream at 1080p 60 fps for smooth output
  • Plug-and-play on Windows, Mac and Linux with no drivers needed
  • Works with OBS, VLC, Amcap and other popular capture software
  • Compact 64 × 28 × 13 mm design weighs only 21.4 g

Specifications

BrandESTONE
SeriesOZC1
ModelOZC1
InterfaceUSB 2.0
FormatYUV / JPEG; Support audio format: L-PCM
Resolution Support1080P
Camera ResolutionUp to 1080p Video
ColorBlack
HDMI1 In
USB Port1
SoftwareSupport most acquisition software, such as VLC / OBS / Amcap, etc
CompatibilityCompatible with Windows, Mac, and Linux. Easily connect your DSLR, camcorder, or action camera to your PC or Mac. Makes it easier for you to have real-time streaming for Twitch, Youtube, OBS, Potplayer and VLC
System RequirementsConnect your DSLR, camcorder or action camera to your Windows, MacOS and Linux.
SpecificationSupport Output Resolution: 1080P@60Hz Max
Support Input Resolution: 4K @60Hz Max
Support Color: 8/10/12bit deep color
Support Cable: AWG26 HDMI standard cable, input up to 15 meters (1080P and below resolution);
Video Output Format: YUV / JPEG; Support audio format: L-PCM
Max Working Current: 0.4A/5V DC
Operating Temperature Range: -10 to +55?
Dimension: 64x28x13 (mm); Weight: 21.4g
FeatureHDMI audio and video signals can be transmitted to the computer and smartphone for preview and storage, now you can enjoy stunning real-time video streaming.
It support HDMI input 3840x2160P and USB output (capture) 1920x1080P video and stereo sound.
Connect (SLR camera, camcorder or motion camera) to (Windows, MacOS, Android or Linux) to easily get real-time streaming media from software such as OBS Studio, Zoom, Potplayer, Twitch, Youtube, and VLC.
No driver or external power supply, suitable for high-definition acquisition, teaching recoding, Gaming, medical imaging, live streamin
Dimensions5.71 x 4.57 x 0.59 inches
Weight1.76 ounces
Package ContentAudio Video Capture Cards 1PCSUser Manual 1PCS
OptionHDMI and USB - 1080p

Questions about this item

Will the USB 2.0 interface throttle my 1080p60 capture during long sessions?

The USB 2.0 connection caps output at 1080p60, and the device draws only 0.4 A at 5 V, so bandwidth and power stay steady.

How hot or loud does the OZC1 get when streaming all day?

It has no fan and runs silently; the rated operating range is –10 °C to +55 °C, so it stays cool under continuous use.

Which cables and ports must I already have to plug this in?

You need an HDMI source, an AWG26 HDMI cable up to 15 m for 1080p signals, and a free USB 2.0 port on a Windows, Mac or Linux machine.
