Black metal 1U rack-mount switch with 16 RJ45 PoE ports and 2 SFP uplinks

ESCAM Technology Co., Ltd

ESCAM Technology Co., Ltd ONV-POE33016PF 18-port network switch 16 PoE 2 SFP 15.4W 250W

SKU CH-KTDE-EAZ24 MPN ONV-POE33016PF

An 18-port Gigabit switch delivers PoE on 16 ports at 15.4W each with a 250W total budget plus two SFP fibre uplinks

  • Switch TypePOE Switch
  • Package Contents1
  • 18 ports connect cameras and uplinks in one switch
  • 16 PoE ports deliver up to 15.4 W each for wireless APs and IP cameras
  • 250 W total power budget feeds all powered devices simultaneously
  • 2 SFP fiber ports extend the network over long distances
  • 1U rack-mount design fits standard cabinets for quick installation

18-Port Gigabit PoE Switch

The ONV-POE33016PF delivers 16 Gigabit PoE ports plus two Gigabit SFP fiber uplinks in a 1U rack-mount chassis. It suits installers who need to power wireless access points and IP cameras over a single cable run. Each copper port auto-negotiates 10/100/1000 Mbps and complies with IEEE 802.3af. The switch requires no software configuration to operate.

250 W Total PoE Budget

The unit supplies up to 15.4 W per PoE port with a 250 W aggregate limit across all sixteen ports. Even-numbered ports use end-span wiring while odd-numbered ports use mid-span wiring. All ports support wire-speed forwarding at 1.488 Mpps for frames between 64 and 1536 bytes. Lightning protection is rated at differential mode ±2 kV and common mode ±4 kV on the AC input.

Plug-and-Play Deployment

Automatic MDI/MDIX and speed negotiation eliminate the need for crossover cables or manual setup. The package contains the switch only; SFP transceivers and rack ears are not included. Silent fanless operation keeps noise to zero in office or server-room environments. PoE power is delivered only to IEEE 802.3af-compliant devices.

Highlights

  • 18 ports connect cameras and uplinks in one switch
  • 16 PoE ports deliver up to 15.4 W each for wireless APs and IP cameras
  • 250 W total power budget feeds all powered devices simultaneously
  • 2 SFP fiber ports extend the network over long distances
  • 1U rack-mount design fits standard cabinets for quick installation

Specifications

BrandONV
ModelONV-POE33016PF
Switch TypePOE Switch
Package Contents1

Questions about this item

How do I mount the ONV-POE33016PF in a standard rack?

The switch uses a 1U rack-mounted design. Secure the front brackets to the rack posts with four screws, then connect the AC power cord before linking any PoE devices.

When will the internal cooling fan need replacement?

The fan is a moving part that wears over time. If airflow noise increases or the chassis feels unusually hot, replace the fan to maintain reliable operation.

What happens if connected devices try to draw more than 250W total?

The 250W power budget is the hard limit. Once combined PoE draw reaches 250W, the switch will deny power to additional ports to protect itself.
