Green PCIe card with two DB9 serial ports and metal bracket

EN-Labs

EN-Labs 2 Port RS-232 PCI Express Card CH382L Full Profile Bracket

SKU CH-72XX-846GJ

Adds two standard RS-232 DB9 serial ports via a single-lane PCI Express 1.0a slot using the WCH CH382L chipset with data rates from 110 to 230400 bps and includes a full-profile bracket

  • TypePCI Express to Serial Port Card
  • External USB Ports2 Port
  • FeaturesConnects more serial devices to your computer easily. Standa
  • Adds two serial ports via a single PCIe x1 slot
  • Data rates from 110 to 230400 bps for legacy and modern gear
  • WCH CH382L chipset keeps connections stable under load
  • Full-profile bracket fits standard desktop cases out of the box
  • Works with Windows 98 through Server 2008 and Linux

Two RS-232 ports on a PCIe x1 card

This EN-Labs adapter adds two standard DB9 male serial ports to a desktop PC through a single-lane PCI Express 1.0a slot. The board uses the WCH CH382L chipset and ships with a full-profile bracket for typical tower chassis. It is intended for users who need to connect legacy serial equipment such as industrial controllers, barcode scanners or older networking gear.

Suits technicians and hobbyists with free x1 slots

The card works with Windows 98 through Windows 8, Server 2003 and 2008, and Linux, covering a wide range of older and current operating systems. Builders whose systems lack an available PCIe x1 slot, or who require USB, parallel or other legacy interfaces instead of RS-232, will not be able to use this product.

Data rate configurable from 110 to 230400 bps

Each port supports asynchronous speeds selectable across the full 110–230400 bps range, with the chipset rated for stable operation up to 115200 bps. This flexibility lets the card match the exact baud-rate requirements of diverse serial devices without additional configuration hardware.

Highlights

  • Adds two serial ports via a single PCIe x1 slot
  • Data rates from 110 to 230400 bps for legacy and modern gear
  • WCH CH382L chipset keeps connections stable under load
  • Full-profile bracket fits standard desktop cases out of the box
  • Works with Windows 98 through Server 2008 and Linux

Specifications

TypePCI Express to Serial Port Card
External USB Ports2 Port
FeaturesConnects more serial devices to your computer easily.
Standard RS-232 DB9 male serial port compliant.
Compliant with Single-Lane (x1) PCI-Express specification revision 1.0a.
Supports up to 2 Fast serial ports
Support PCIe Power Management
Interface: 1-Lane (x1) PCI-Express port
Output: 2 external RS-232 DB9 ports
Installation with Full Profile Bracket
Data transfer rate support up to 115200bps (Serial Port)
Automatically selects IRQ (Interrupt Request) & IO address
Supports IRQ sharing
Multi card capability allow for upgrade with additional serial cards
With Stable and reliable WCH

Questions about this item

What PCI-Express lane width and revision does the card use, and what serial speed does that allow?

It plugs into a single x1 lane compliant with PCI-Express revision 1.0a and drives both DB9 ports at up to 230400bps.

Which bracket style ships with the card, and what slot height does it need?

A full-profile bracket is included, so the card requires a standard-height rear opening in the chassis.

How is the card installed, and what step is often missed?

Insert it into a free x1 or wider PCIe slot, secure the full-profile bracket screw, then install the WCH CH382L driver for Windows 98 through Server 2008 or Linux before the ports will appear.
