Yellow and grey digital clamp meter with dual display and clamp jaws open

Electrical System Tool 12G

SKU CH-ZSKG-R04RK

A digital clamp meter measuring AC current to 400 A, AC/DC voltage to 750 V AC / 1000 V DC, microamps, capacitance, resistance, frequency and continuity with NCV and dual display

  • FeaturesManual (Eng) Yes Test Leads ATL55 Batteries AAA (2) Pouch/Ca
  • Height1.49 L x 2.98 W x 8.7 H inches
  • Width1.49 L x 2.98 W x 8.7 H inches
  • Length1.49 L x 2.98 W x 8.7 H inches
  • Weight0.65 ounces
  • Sports Team1 Piece
  • Dual 4000-count display shows readings clearly
  • Measures AC current up to 400A with clamp
  • Detects live wires 24 to 600V AC non-contact
  • Tests capacitance 4000µF and frequency on site
  • Auto-ranging and auto power off simplify use

DL369 Clamp Meter for Electrical Testing

The DL369 is a dual-display clamp meter designed for electrical maintenance and live-conductor current measurement. It provides auto-ranging 4000-count readings for AC current up to 400A and AC/DC voltage up to 750V AC or 1000V DC. The tool includes non-contact voltage detection from 24 to 600V AC, capacitance to 4000µF, resistance to 40MΩ, plus frequency, duty cycle, diode and continuity functions. Test leads, AAA batteries, a manual and a zippered pouch are supplied.

Suitable Users and Limitations

This meter suits electricians and HVAC technicians needing a single instrument for clamp current, voltage, capacitance and safety-rated NCV alerting on CAT III 600V and CAT II 1000V circuits. It is not for users who require DC current clamp measurement, true-RMS accuracy, data logging, wireless connectivity, or higher count resolution beyond the 4000-count display.

Deciding Specification — 400A AC Clamp Range

The defining specification is the 400A AC clamp measurement capability combined with 2000µA AC/DC microamp resolution. If the application demands current readings above 400A, DC clamp functionality, or a higher display count, a different meter class is required.

Highlights

  • Dual 4000-count display shows readings clearly
  • Measures AC current up to 400A with clamp
  • Detects live wires 24 to 600V AC non-contact
  • Tests capacitance 4000µF and frequency on site
  • Auto-ranging and auto power off simplify use

Specifications

BrandaFe Power
FeaturesManual (Eng) Yes Test Leads ATL55 Batteries AAA (2) Pouch/Cases AC519, Battery Powered, true
Height1.49 L x 2.98 W x 8.7 H inches
Width1.49 L x 2.98 W x 8.7 H inches
Length1.49 L x 2.98 W x 8.7 H inches
Weight0.65 ounces
Sports Team1 Piece
TypeClamp

Questions about this item

What test leads are included so the clamp meter is ready to use right away?

The kit ships with ATL59 test leads, two AAA batteries, a manual and a zippered pouch so you can start measuring immediately.

Will the non-contact voltage alert still trigger on older 24 V control circuits I keep in service?

Yes, the NCV function detects AC voltage from 24 V up to 600 V, so legacy low-voltage wiring will still sound the audible warning.

How can I confirm the dual 4000-count display is reading correctly after I power it on?

Select a known voltage source such as a 750 V AC or 1000 V DC reference; the dual display should show the expected value and the low-battery indicator must remain off.
