Silver rack-mount network switch with 44 RJ-45 ports and four SFP slots on the front panel

Edge-Core Networks Corporation

Edge-Core Networks Corporation ECS4610-50T 44-port Gigabit stackable network switch

SKU CH-NS8Z-R5Y7P MPN ECS4610-50T

A 44-port Gigabit stackable Layer 3 switch with four combination SFP slots, two 10G module bays and 16K MAC table

  • FormatStackable
  • StandardsIEEE 802.3-2005 Ethernet, Fast Ethernet, Gigabit Ethernet Fu
  • Primary Ports44 x RJ-45 10/100/1000BASE-T 4 x Combination (RJ-45/SFP) Gig
  • Primary Port Speed10/100/1000Mbps
  • MAC Address Table16K
  • VLAN SupportIP subnet based VLAN Private VLAN Isolated Private VLAN GVRP
  • Layer 3 routing with 44 Gigabit RJ-45 ports
  • Stackable design with two 10GBASE extender module slots
  • 8 hardware QoS queues per port for traffic prioritisation
  • Advanced security including IEEE 802.1X and RADIUS authentication
  • 16K MAC address table and 2 MB packet buffer

44-port Gigabit stackable L3 switch

The Edge-Core ECS4610-50T is a stackable Layer 3 Gigabit Ethernet switch with 44 RJ-45 10/100/1000BASE-T ports and four combination RJ-45/SFP Gigabit ports. It includes two module slots for optional 10GBASE XFP transceivers. The unit supports IEEE 802.3ae 10 Gigabit Ethernet and a range of L2/L3 switching standards.

Suitable deployments and limits

This switch suits service-provider edge aggregation, enterprise wiring closets, data-centre aggregation and network-core deployments needing resilient stacking and wire-speed L3 routing. Buyers who need Power over Ethernet for attached devices, higher port density beyond 44 copper ports, or native 10GBASE-T copper uplinks should look at other models.

Stackable architecture with 10G uplinks

The defining specification is the stackable design combined with two 10GBASE extender module slots for XFP transceivers. This allows multiple units to operate as a single logical switch while providing optional 10 Gigabit uplinks for aggregation or core connectivity.

Highlights

  • Layer 3 routing with 44 Gigabit RJ-45 ports
  • Stackable design with two 10GBASE extender module slots
  • 8 hardware QoS queues per port for traffic prioritisation
  • Advanced security including IEEE 802.1X and RADIUS authentication
  • 16K MAC address table and 2 MB packet buffer

Specifications

BrandEdge-Core
ModelECS4610-50T
FormatStackable
StandardsIEEE 802.3-2005
Ethernet, Fast Ethernet, Gigabit Ethernet
Full-duplex flow control
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.3D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1Q Virtual LAN
ISO/IEC 8802-3 CSMA/CD
Primary Ports44 x RJ-45 10/100/1000BASE-T
4 x Combination (RJ-45/SFP) Gigabit Ethernet
Primary Port Speed10/100/1000Mbps
MAC Address Table16K
VLAN SupportIP subnet based VLAN
Private VLAN Isolated
Private VLAN
GVRP/GARP
802.1v protocol
Voice VLAN
VLAN translation
IPv6 VLANs
VLAN Trunking
Buffer MemoryPacket Buffer 2MB
SecurityPort security
IP Source Guard
Supports IEEE 802.1X port-based and MAC-based access control
IP filter configuration for management interface (SNMP, Telnet, Web)
RADIUS authentication
Access Control List
SSH v2
HTTPS/SSL
MAC filter
Dynamic ARP Inspection
Link detection
StackableYes
SNMPRFC 1907 SNMPv2-MIB (MIB-II)
RFC 2011 IP-MIB (MIB-II)
RFC 2012 TCP-MIB (MIB-II)
RFC 2013 UDP-MIB (MIB-II)
IEEE 802.1X IEEE8021-PAE-MIB
RFC 1493 Bridge MIB
RFC 2863 IF-MIB
RFC 2819 RMON MIB
RFC 2618 RADIUS MIB
RFC 2665 Etherlike MIB
RFC 2737 Entity MIB
RFC 2674 P-bridge, Q-bridge
V-Bridge MIB
RFC 3036 MAU MIB
RFC 1612 DNS Reslover MIB
RFC 3411 SNMP Framework
RFC 3412 SNMP MPD MIB
RFC 3413 SNMP Target MIB, SNMP Notify MIB
RFC 3415 SNMP View-Based ACM MIB
SNMP Trap Supported:
RFC 1215, 1907, 2863, 1493, 1757, 2819
Private MIB
QoSPriority Queues: 8 hardware queues per port
Traffic classification based on IEEE 802.1p CoS, IP Precedence, DSCP,
TCP/UDP port number, Access Control List, marking
DiffServ
Supports WRR and strict priority
Port rate limiting
Layer3
Module Support2 x 10GBASE extender module slots for XFP transceivers
PowerVoltage: 100-240V AC auto-ranging
Frequency: 47-63Hz
Current:
0.995 A @ 110 VAC (without expansion XFP modules)
1.21 A @ 110 VAC (with two expansion XFP modules)
0.54 A @ 240 VAC (without expansion XFP modules)
0.605 A @ 240 VAC (with two expansion XFP modules)
Power Consumtion
98.16 Watts (without expansion XFP modules)
104.16 Watts (with two expansion XFP modules)
Dimensions17.3"W x 16.3"D x 1.7"H
Weight13.4 lbs.
Temperature0°C to 50°C (32°F to 122°F)
Humidity5% - 95%, Non-condensing
FeaturesFlash Memory: 64MB
Out-of-Band Management: Console Port
256MB SDRAM for CPU
Forwarding Rate: 95.2Mpps
Switching Capacity: 128Gbps
L2 Features
Spanning Tree
Loopback detection
Auto edge port
BPDU filter/guard
Jumbo Frame : 9K
IGMP Snooping v1/v2/v3
Select Q-in-Q
L3 Features
Host table: 8K
Route table: 8K
Static route table: 512
Multicast table: 1K
Unicast routing
Static unicast routes
RIP v1/v2
OSPF
BGP
Multicast routing
PIM-DM
PIM-SM
IGMP v1/v2/v3
IGMP v3 proxy
IP Redundancy
Proxy ARP
UDP Helper
IPv6 Features
IPv4/IPv6 Dual Protocol Stack
IPv6 Address Types : Unicast, Multicast
ICMPv
Shipping weight6.80 kg
Package size533 × 470 × 127 mm

Questions about this item

How many MAC addresses can the 16K table hold before entries start being aged out?

The table supports 16K entries; when full, the switch removes the least-recently-used addresses to make space for new ones.

What is the power draw at 110 VAC when both 10GBASE extender slots are populated?

The switch draws 1.21 A at 110 VAC with two XFP modules installed.

What transceivers are needed to use the two 10GBASE extender module slots on the rear panel?

The slots accept XFP transceivers, which must be purchased separately.
