Eaton XTPRP63BC1 manual motor protector, transparent rotary selector, DIN-rail mount, screw terminals

Eaton

Eaton XTPRP63BC1 Manual Motor Protector 0.63A Rotary Frame B

SKU CH-C1TD-MFXZ0

Three-pole manual motor protector with 0.63 A thermal overload range, 600 V AC rating and DIN-rail screw-terminal mounting

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Thermal overload protection with 0.4 A to 0.63 A adjustable range
  • Three-pole 600 V AC rating for industrial motor circuits
  • DIN-rail screw-terminal mounting fits standard control panels
  • IEC starter design in Frame B rotary format
  • Compact 3.46 in depth saves enclosure space

Manual Motor Protector 0.63 A

This Eaton XTPR Series manual motor protector handles three-phase AC loads up to 0.63 A with a 600 V rating. It mounts on a DIN rail and uses screw terminals for wiring. The rotary selector switch provides manual on-off control. It suits industrial control panels that need basic overload protection without a full starter assembly.

Installation notes

The unit clips onto standard DIN rail and connects with screw terminals, so only a screwdriver is required. No enclosure is included, so install it inside a suitable cabinet. The overload relay adjusts between 0.4 A and 0.63 A; set it to match the motor nameplate current. Verify the panel depth allows the 3.46 in. body plus wiring clearance.

Three-pole 600 V AC rating

This protector is built for three-phase circuits at up to 600 V AC. If your supply voltage exceeds that value or you need a different pole count, this model will not meet the requirement. The fixed 0.63 A maximum setting also means it cannot protect motors drawing more current.

Highlights

  • Thermal overload protection with 0.4 A to 0.63 A adjustable range
  • Three-pole 600 V AC rating for industrial motor circuits
  • DIN-rail screw-terminal mounting fits standard control panels
  • IEC starter design in Frame B rotary format
  • Compact 3.46 in depth saves enclosure space

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How can I verify the Eaton XTPRP63BC1 is protecting the motor correctly after wiring it to the DIN rail?

With power applied, the rotary selector switch should stay in the ON position and the motor should run without the device tripping; if an overload occurs, the thermal mechanism will open the circuit at the 0.63 A maximum setting.

What accessories are included with the Eaton XTPRP63BC1 and what must be purchased separately?

The unit itself is supplied with screw terminals for wiring; DIN rail mounting hardware, enclosure, and supply conductors are not included and must be sourced separately.

Which current setting should I select on the Eaton XTPRP63BC1 for my application?

Adjust the thermal overload dial between the minimum 0.4 A and maximum 0.63 A to match the motor’s full-load current; the 600 V AC, 3-pole rating covers standard industrial supplies.
