Transparent rotary motor protector, three-pole, DIN-rail mount

Eaton

Eaton XTPR1P6BC1 Manual Motor Protector 1.6 A 600 V 3-pole

SKU CH-CZNH-Y9MAS

Protects motors up to 1.6 A at 600 V AC with three-pole rotary operation and DIN-rail mounting

  • TypeRotary
  • ColorTransparent
  • Protects motors up to 1 hp at 600 V AC with 3-pole coverage
  • Adjustable overload range from 1 A to 1.6 A for precise trip settings
  • DIN-rail mounting enables fast panel installation without extra hardware
  • Rotary selector switch gives clear on/off/trip status at a glance
  • Rated for 1/10 hp single-phase at 240 V and 3/4 hp three-phase at 480 V

Eaton XTPR1P6BC1 motor protector

The Eaton XTPR1P6BC1 is a manual motor protector rated for 1.6 A and 600 V AC across three poles. It suits industrial control panels that need adjustable overload protection for small single-phase or three-phase motors. The rotary selector switch allows direct current setting between 1 A and 1.6 A without extra tools.

DIN-rail mounting and rotary selector

The unit mounts on standard DIN rail and requires no separate enclosure, saving panel space for compact builds. Its transparent rotary dial shows the chosen trip current clearly, reducing set-up errors during commissioning or maintenance. No additional thermal elements are needed for operation.

Simple installation with common pitfalls

Wiring is straightforward thanks to the three-pole layout and accessible terminals, but the lack of a built-in enclosure means you must provide suitable IP-rated housing for the installation environment. Verify that the 1.6 A maximum setting matches the motor full-load current before energising the circuit. Incorrect trip-current selection is the most frequent cause of nuisance tripping or missed overload events.

Highlights

  • Protects motors up to 1 hp at 600 V AC with 3-pole coverage
  • Adjustable overload range from 1 A to 1.6 A for precise trip settings
  • DIN-rail mounting enables fast panel installation without extra hardware
  • Rotary selector switch gives clear on/off/trip status at a glance
  • Rated for 1/10 hp single-phase at 240 V and 3/4 hp three-phase at 480 V

Specifications

BrandEaton
ModelXTPR1P6BC1
TypeRotary
ColorTransparent

Questions about this item

Will the thermal overload element in the XTPR1P6BC1 need periodic replacement?

The thermal overload is built into the protector and calibrated from 1 A to 1.6 A; it does not require a separate replacement schedule under normal operation.

What stops the XTPR1P6BC1 from carrying more current during a long motor run?

The maximum overload relay setting of 1.6 A is the first limit reached; the device trips when the motor current exceeds that value.

How much heat does the XTPR1P6BC1 add to the cabinet when it runs all day?

At its 1.6 A rating the protector dissipates only a few watts, so temperature rise inside a DIN-rail enclosure remains minimal.
