Transparent rectangular motor protector with push button operator and DIN rail mounting

Eaton

Eaton XTPB1P6BC1 Manual Motor Protector 1.6A Push Button Frame B video accessory

SKU CH-RGBF-WWV52

Protects three-phase motors up to 1.6 A with push-button control and DIN-rail mounting

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Three-pole protection for three-phase motors
  • 6 A overload setting with 1 A minimum adjustment
  • Push-button operator for direct manual control
  • 600 V AC maximum voltage rating
  • DIN-rail mounting fits standard control panels

Manual Motor Protector 1.6 A

The Eaton XTPB1P6BC1 is a three-pole manual motor protector rated for 1.6 A continuous current. It mounts on DIN rail and uses a push-button operator for local control. The unit suits single-phase loads at 240 V AC up to 1/10 hp and three-phase loads at 480 V AC up to 3/4 hp.

Thermal overload behaviour

An adjustable thermal element trips between 1 A and 1.6 A to protect the motor from sustained overload. The mechanism rides through normal start-up current without nuisance tripping. Once tripped, the push button must be reset manually, giving a clear indication of a fault condition.

600 V AC voltage limit

The protector is rated for a maximum of 600 V AC, so it cannot be applied on systems exceeding that voltage. Its NEMA open construction means it must be installed inside a suitable enclosure for personnel safety. The fixed 1.6 A upper setting also limits use to motors with full-load current at or below that value.

Highlights

  • Three-pole protection for three-phase motors
  • 6 A overload setting with 1 A minimum adjustment
  • Push-button operator for direct manual control
  • 600 V AC maximum voltage rating
  • DIN-rail mounting fits standard control panels

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How much heat does the 1.6 A XTPB manual motor protector generate when running continuously?

The device is rated for a maximum overload relay current setting of 1.6 A and a minimum of 1 A, with a maximum voltage rating of 600 V AC.

What DIN rail and voltage supply are required to install this Frame B protector?

It mounts on a standard DIN rail and operates on three-phase systems up to 600 V AC, with single-phase 240 V AC rated at 1/10 hp and three-phase 480 V AC at 3/4 hp.

Will this three-pole push-button protector coordinate with an existing 480 V AC motor starter?

Yes, it provides three-phase protection at 480 V AC up to 3/4 hp and at 600 V AC up to 1 hp, with a 1.6 A current setting range of 1 to 1.6 A.
