Eaton XTPB016BC1 manual motor protector with transparent push-button housing

Eaton

Eaton XTPB016BC1 Manual Motor Protector 16A Push Button Frame B

SKU CH-XS25-6TKCP

A three-pole manual motor protector rated at 16 A with push-button operation for circuits up to 600 V AC

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Protects motors up to 16 A continuous current
  • Handles three-phase loads at 208 V, 240 V, 480 V and 600 V AC
  • Rated for single-phase 1 hp at 120 V and 2 hp at 240 V AC
  • Push-button operator gives direct manual control
  • Three-pole design covers all phases in one unit

Eaton XTPB 16 A Manual Motor Protector

This Eaton XTPB manual motor protector provides overload protection for three-phase motors up to 16 A. It uses a push-button operator for manual start and stop control. The unit is rated for a maximum voltage of 600 V AC. It suits industrial control panels requiring basic motor safeguarding.

Three-pole frame B fits DIN rail mounting

The three-pole design fits standard DIN rail installations inside control cabinets. Push-button operation frees panel space by removing the need for a separate rotary handle or external actuator. Transparent housing allows visual confirmation of contact status. Wiring connects directly to the front-access terminals.

Handles up to 10 hp at 480 V and 600 V

At 480 V AC and 600 V AC three-phase the protector covers motors up to 10 hp. At 240 V AC three-phase it handles 5 hp and at 208 V AC three-phase it handles 3 hp. Single-phase ratings reach 2 hp at 240 V AC and 1 hp at 120 V AC. The fixed 16 A overload setting limits use to motors within that current range.

Highlights

  • Protects motors up to 16 A continuous current
  • Handles three-phase loads at 208 V, 240 V, 480 V and 600 V AC
  • Rated for single-phase 1 hp at 120 V and 2 hp at 240 V AC
  • Push-button operator gives direct manual control
  • Three-pole design covers all phases in one unit

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

What is the maximum current the 16 A overload relay can sustain before it trips?

The overload relay trips at its maximum setting of 16 A, protecting the motor from sustained overcurrent.

How much heat does the three-pole protector dissipate when running continuously at 16 A?

Continuous operation at the rated 16 A produces heat typical for a Frame B manual motor protector; ensure the enclosure has adequate ventilation.

What supply voltage and phase must the installation provide for the 600 V AC rating?

A three-phase supply up to 600 V AC is required to match the protector’s maximum voltage rating.
