Transparent industrial motor protector with push-button operator and DIN rail mounting clips

Eaton

Eaton XTPB001BC1 Manual Motor Protector 1A Push Button Frame B

SKU CH-1PTW-14EZ1

Three-phase manual motor protector with push-button operation, adjustable thermal overload from 0.63 A to 1 A, rated for 600 V AC and 1/2 hp at 480 V

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Protects motors up to 600 V AC with three-pole thermal overload
  • Push-button operator gives quick manual control on the panel
  • Adjustable trip range from 0.63 A to 1 A matches load precisely
  • Rated for 1/2 hp at both 480 V and 600 V three-phase
  • DIN-rail mount fits standard industrial enclosures without extra hardware

Eaton XTPB001BC1 Manual Motor Protector

The Eaton XTPB001BC1 is a manual motor protector rated for 1 A continuous current. It provides thermal overload protection for three-phase motors up to 1/2 hp at 480 V AC or 600 V AC. The unit mounts on a DIN rail and uses a push-button operator for manual control.

Check your motor and panel before ordering

Verify that the motor full-load current falls between .63 A and 1 A to match the adjustable overload range. Confirm the supply voltage does not exceed 600 V AC and that the application uses three-phase power. Ensure the panel has DIN rail mounting space and that no enclosure is required for the installation.

Suits simple three-phase motor circuits

This protector fits installations needing basic thermal overload and manual on/off control for small three-phase motors. It is not suited for applications requiring magnetic trip, short-circuit protection, or an integrated contactor. Buyers who need higher current settings, enclosed devices, or automatic reset functions should look at alternative devices.

Highlights

  • Protects motors up to 600 V AC with three-pole thermal overload
  • Push-button operator gives quick manual control on the panel
  • Adjustable trip range from 0.63 A to 1 A matches load precisely
  • Rated for 1/2 hp at both 480 V and 600 V three-phase
  • DIN-rail mount fits standard industrial enclosures without extra hardware

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Does the Eaton XTPB001BC1 ship with any accessories or must I purchase the DIN rail clip and wiring separately?

The protector mounts on a standard DIN rail and uses screw terminals for wiring; no extra clips or cables are included in the box.

Should I select the 0.63 A or 1 A overload setting for a motor that draws exactly 1 A at 480 V three-phase?

Set the thermal dial to its maximum 1 A position; the adjustable range spans 0.63 A to 1 A so the 1 A setting matches the motor’s full-load current.

What does the 600 V AC rating mean when the protector is installed on a 480 V three-phase panel?

The 600 V AC maximum voltage rating exceeds the 480 V supply, so the device is fully rated for the panel’s line-to-line voltage.
