Transparent rectangular overload relay with front-mounted adjustment dial and terminal block

Eaton

Eaton XTOM006AC1 Overload Relay 4 A 6 A 1NC/1NO

SKU CH-07ER-QCRJJ

A thermal overload relay for three-phase circuits with a 4 A to 6 A setting range and Trip Class 10

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Thermal protection for three-phase circuits up to 6 A
  • Adjustable current range from 4 A to 6 A
  • Trip Class 10 ensures fast overload response
  • Auto and manual reset options for flexible recovery
  • Certified to IEC 60947, CE, CSA, ATEX and RoHS standards

Eaton XTOM006AC1 Overload Relay

The Eaton XTOM006AC1 is a thermal overload relay designed for three-phase motor protection. It mounts directly to compatible Series XT mini contactors with Frame Size A. The unit provides adjustable current settings between 4 A and 6 A and includes auxiliary contacts rated 1NO/1NC for control circuits.

Industrial motor control panels

This relay suits panels that use Series XT mini contactors and require IEC-style thermal protection with Trip Class 10 response. It is not suited for applications needing NEMA-sized starters, electronic overload functions, or contactor frames other than Frame Size A. Buyers needing different current ranges or mounting styles should look at other models.

Adjustable 4 A to 6 A range

The relay comfortably handles motors with full-load currents within the 4 A to 6 A window and trips on sustained overloads according to Trip Class 10 timing. It runs out of headroom for motors drawing above 6 A or for installations that demand a fixed NEMA size classification. The auto and manual reset options give flexibility after a trip event.

Highlights

  • Thermal protection for three-phase circuits up to 6 A
  • Adjustable current range from 4 A to 6 A
  • Trip Class 10 ensures fast overload response
  • Auto and manual reset options for flexible recovery
  • Certified to IEC 60947, CE, CSA, ATEX and RoHS standards

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Which contactor series must I already own to mount the XTOM006AC1 overload relay directly?

The relay is designed for direct mounting on Eaton XT Mini Contactors, Frame Size A, so you need a compatible contactor from that series.

Will the 4 A to 6 A thermal overload range coordinate with older motor starters using Trip Class 10?

Yes, the relay operates at Trip Class 10, matching the standard trip profile used by many legacy starters.

How can I verify the relay is protecting the circuit correctly after installation?

Apply load current within the 4 A to 6 A range; the thermal element should trip at the calibrated threshold and the 1NO/1NC auxiliary contacts will change state to signal the fault.
