Transparent electronic overload relay with three-pole base and reset button

Eaton

Eaton XTOE045CGSS Overload Relay 9-45 A 1NO/1NC Trip Class 10/20

SKU CH-JTNG-N3VS7

An electronic overload relay protects three-phase motors with a 9 A to 45 A setting range and trip class 10/20

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Adjustable protection from 9 A to 45 A
  • Selectable trip class 10 or 20 for motor start profiles
  • 1NO/1NC auxiliary contact simplifies control wiring
  • Auto and manual reset options reduce downtime
  • CE, CSA and UL listed for code compliance

Eaton Overload Relay for Mini Contactors

The Eaton XTOE045CGSS is an electronic overload relay designed for three-phase motor protection in industrial automation. It fits XT Mini Contactors and offers a current setting range of 9 A to 45 A with selectable Trip Class 10 or 20. The unit includes a 1NO/1NC auxiliary contact for status signalling.

Compatibility Check Before Ordering

Verify that your motor starter uses a Series XT Mini Contactor with Frame Size C for correct mechanical fit. Confirm the motor full-load current falls within the 9 A to 45 A adjustment range and that the required trip class matches Class 10 or 20. Ensure the control circuit can accommodate the auto or manual reset modes provided.

Build Quality and Daily Use

The transparent housing allows visual inspection of internal components without removal. Separate mounting style means the relay installs independently of the contactor, simplifying panel layout and wiring access. CE, CSA and UL Listed markings confirm compliance with major safety standards for industrial environments.

Highlights

  • Adjustable protection from 9 A to 45 A
  • Selectable trip class 10 or 20 for motor start profiles
  • 1NO/1NC auxiliary contact simplifies control wiring
  • Auto and manual reset options reduce downtime
  • CE, CSA and UL listed for code compliance

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

What components are included with the XTOE045CGSS overload relay and what must be sourced separately?

The relay includes auto and manual reset functions with 1NO/1NC auxiliary contacts. Thermal units are not applicable and the unit is separately mounted, so a compatible XT mini contactor and mounting hardware must be obtained separately.

Which trip class setting should be selected for the 9 to 45 A operating range?

The relay offers Trip Class 10 and 20 settings. Choose Class 10 for faster motor protection or Class 20 for applications with longer start-up times within the 9 to 45 A current range.

How does the 45 A maximum current setting perform in a three-phase IEC motor circuit?

The electronic overload relay protects three-phase motors up to 45 A with adjustable settings from 9 A. It meets CE, CSA and UL Listed standards for IEC-style installations.
