Eaton XTD2G1A Toggle Switch SPDT 3 Connections On/Off/Momentary On 3/4 hp
SPDT toggle switch with three connections, On/Off/Momentary On action, rated 10 A at 277 V, 15 A at 28 V, 20 A at 125 V and 3/4 hp, quick-connect terminals, 0.50 in mounting hole.
- SPDT switching with On/Off/Momentary On function for flexible control
- 15 A at 28 V DC rating supports demanding low-voltage circuits
- 10 A at 277 V AC capacity handles higher-voltage applications
- 3/4 hp motor rating enables direct small-motor control
- 50 in mounting hole with quick-connect terminals simplifies panel installation
Industrial Toggle Switch for Motor Control
The Eaton XTD2G1A is a single-pole double-throw toggle switch rated for three-quarter horsepower motor loads. It provides On/Off/Momentary On switching with three quick-connect terminals for straightforward wiring in machinery panels. The switch carries a 20 A rating at 125 V AC and 10 A at 277 V AC for resistive circuits.
Sustained Load Behaviour
Under continuous operation the contacts are rated for 15 A at 28 V DC and 15 A at 28 V AC, while the AC horsepower rating remains at three-quarter hp. Quick-connect terminals maintain a secure connection during vibration typical of industrial equipment. The switch function allows momentary activation that returns to the centre off position when released.
Thermals Noise and Power Draw
The device is a passive electromechanical component so it generates no audible noise and draws no control power of its own. Silver-coloured actuator and stem withstand normal panel temperatures without active cooling. A 0.50 in mounting hole accepts standard panel cut-outs and the switch is UL Listed and RoHS compliant.
Highlights
- SPDT switching with On/Off/Momentary On function for flexible control
- 15 A at 28 V DC rating supports demanding low-voltage circuits
- 10 A at 277 V AC capacity handles higher-voltage applications
- 3/4 hp motor rating enables direct small-motor control
- 50 in mounting hole with quick-connect terminals simplifies panel installation
Specifications
| Brand | EATON |
|---|
Questions about this item
How much heat or power draw should I expect from the XTD2G1A toggle switch during continuous operation?
The switch itself draws no measurable power and generates no heat; it simply carries the load up to 10 A at 277 V AC, 15 A at 28 V DC, 20 A at 125 V AC, or 3/4 hp motor rating.
What wiring and panel cut-out do I need to have ready before installing this switch?
You need a 0.50 in diameter mounting hole and quick-connect terminals for three wires matching the SPDT On/Off/Momentary On circuit.
Will the 0.500 in stem and 0.64 in actuator fit the existing panel and knob on my older machine?
The switch mounts in a 0.50 in hole with a 0.47 in stem length and 0.64 in actuator length, so it matches panels and knobs built to those dimensions.
