Eaton XTD2E1A Toggle Switch SPDT 10A 277V Quick Connect
A momentary toggle switch rated 10 A at 277 V with quick-connect terminals for panel mounting
- SPDT momentary action gives three-position control
- 10 A at 277 V AC handles heavy-duty circuits
- Quick-connect terminals speed up panel wiring
- 50 in mounting hole fits standard panels
- UL listed and RoHS compliant for code approval
Eaton XTD2E1A Toggle Switch SPDT 10A 277V
The Eaton XTD2E1A is a momentary toggle switch rated for 10 amps at 277 volts AC and 20 amps at 125 volts AC. It features a SPDT contact form with three connections and quick-connect terminals for fast wiring. The actuator length is 0.64 inches and the stem diameter is 0.500 inches. It carries UL listing and RoHS compliance.
Suits Panels Needing 0.50 Inch Mount Hole
This switch fits panels with a 0.50 inch diameter mounting hole and a stem length of 0.47 inches. It is intended for circuits requiring momentary on/off/momentary on action at the listed ratings. Buyers needing a maintained on/off position or a different contact form should look elsewhere. Applications requiring higher voltage or current ratings than 277 volts AC are not served by this device.
10 Amp 277 Volt AC Rating Decides Fit
The defining specification is the 10 ampere rating at 277 volts AC. This figure determines whether the switch can handle the intended load safely. Verify the circuit voltage and current against this rating before purchase. The 15 ampere rating at 28 volts DC and 20 ampere rating at 125 volts AC provide additional application flexibility.
Highlights
- SPDT momentary action gives three-position control
- 10 A at 277 V AC handles heavy-duty circuits
- Quick-connect terminals speed up panel wiring
- 50 in mounting hole fits standard panels
- UL listed and RoHS compliant for code approval
Specifications
| Brand | EATON |
|---|
Questions about this item
How do I verify the Eaton XTD2E1A toggle switch is operating correctly after wiring the quick-connect terminals?
Apply power and toggle the actuator through its momentary on/off/momentary on positions; the three quick-connect terminals should show continuity changes matching the SPDT contact form.
What components are included with the Eaton XTD2E1A and what must be sourced separately?
The switch includes panel-mounting hardware for a 0.50 in diameter hole; quick-connect mating terminals and wiring are not supplied.
Which Eaton XTD2E1A rating should I select for a 277 V AC circuit?
Choose the 10 A @ 277 V AC rating; the same unit also carries 15 A @ 28 V DC and 20 A @ 125 V AC ratings for other applications.
