Silver toggle switch with threaded stem and three quick-connect terminals

Eaton

Eaton XTD2B1A SPDT Toggle Switch 10A 277V Quick Connect

SKU CH-JW5E-J5Y9Z

SPDT toggle switch rated 10 A at 277 V AC with quick-connect terminals and 0.50 in mounting hole

  • SPDT on/off/on switching gives three-position control
  • 10 A at 277 V AC rating handles mains-level loads
  • Quick-connect terminals speed up wiring installation
  • 50 in mounting hole fits standard panel cut-outs
  • UL listed and RoHS compliant for regulated projects

SPDT Toggle Switch for 10 A AC Circuits

The Eaton XTD2B1A is a single-pole double-throw toggle switch rated for 10 A at 277 V AC and 20 A at 125 V AC. It provides an On/Off/On switching function with three quick-connect terminals for fast wiring. The actuator length is 0.64 in and the stem length is 0.47 in with a 0.500 in diameter thread. It mounts in a 0.50 in diameter panel hole.

Suits Panel-Mount Power Switching Up to 10 A

This switch suits installers who need a compact SPDT device for AC power control in machinery, panels or automotive electrical systems where quick-connect terminals are preferred. It is not for circuits exceeding 10 A at 277 V AC or 20 A at 125 V AC. It is also not for applications requiring a momentary action or a different contact form such as DPST or DPDT.

10 A 277 V AC Rating Decides Fit

The defining specification is the 10 A at 277 V AC contact rating, which sets the maximum load the switch can safely interrupt on mains-voltage AC circuits. Verify that your load current and voltage stay within this limit and the 15 A at 28 V DC rating before selecting this part. The UL Listed and RoHS markings confirm compliance with common safety and substance restrictions.

Highlights

  • SPDT on/off/on switching gives three-position control
  • 10 A at 277 V AC rating handles mains-level loads
  • Quick-connect terminals speed up wiring installation
  • 50 in mounting hole fits standard panel cut-outs
  • UL listed and RoHS compliant for regulated projects

Specifications

BrandEATON

Questions about this item

Will this SPDT toggle switch handle the same 277 VAC circuits I already run with 10 A loads?

Yes, the switch is rated for 10 A at 277 VAC, matching those existing circuit requirements.

How can I confirm the switch is toggling correctly once installed?

Operate the actuator through the On/Off/On positions and verify continuity across the three quick-connect terminals with a multimeter.

Does the package include the mounting hardware, or do I need to buy a 0.50 in panel hole cutter separately?

Panel mounting hardware is included; you only need to provide a 0.50 in diameter mounting hole in your panel.
