Eaton XTCEXFBG11 front auxiliary contact, transparent, 2.800 length

Eaton

Eaton XTCEXFBG11 Front Aux Seq B 1NO/1NC XT Frame D-G

SKU CH-EP9K-K27T7

Front-mount auxiliary contact adds one normally-open and one normally-closed circuit rated 16 A at 500 V AC for XT frame D-G contactors

  • TypeSequence B
  • Length2.800
  • ColorTransparent
  • Weight0.11
  • Front-mount auxiliary contact fits XT frames D–G
  • 16 A AC current rating with 500 V maximum voltage
  • One normally open and one normally closed contact
  • Screw clamp terminals for secure wiring
  • 800 sequence B auxiliary module weighs 0.11 kg

Eaton XTCEXFBG11 Auxiliary Contact

This Eaton XTCEXFBG11 auxiliary contact mounts on the front of XT Frame D through G control relays. It provides two poles with one normally open and one normally closed contact rated for 16 A at up to 500V AC. Screw clamp terminals simplify wiring in industrial control panels.

Sequence B contact block for XT frames

The block replaces a missing or worn front-mounted auxiliary contact on compatible Eaton XTRE control relays. It is the correct choice when a panel design calls for Sequence B operation and the existing relay uses Frame D, E, F or G. The jump is worth it only if the application specifically requires this contact arrangement and frame fit.

Check frame size and mounting position

Verify that the target relay is an XTRE series unit in Frame D, E, F or G before ordering. Confirm the panel layout has front mounting space and that the control circuit voltage does not exceed 500V AC. Ensure the screw clamp terminal style matches the wiring practice used in the enclosure.

Highlights

  • Front-mount auxiliary contact fits XT frames D–G
  • 16 A AC current rating with 500 V maximum voltage
  • One normally open and one normally closed contact
  • Screw clamp terminals for secure wiring
  • 800 sequence B auxiliary module weighs 0.11 kg

Specifications

BrandEaton
ModelXTCEXFBG11
TypeSequence B
Length2.800
ColorTransparent
Weight0.11

Questions about this item

What screw-clamp terminal spacing does the XTCEXFBG11 need for front mounting on Frame D-G?

The auxiliary contact mounts on the front of XT Frame D, E, F or G using screw-clamp terminals rated for 16 A at 500 V AC.

Which wiring step is most often missed when fitting the 1NO/1NC contact block?

Installers frequently forget to tighten both screw-clamp terminals for the normally-open and normally-closed circuits after seating the block on the relay front.

When should the XTCEXFBG11 auxiliary contact be replaced in a control circuit?

Replace the block if the 16 A / 500 V AC contacts show pitting, overheating discoloration, or fail continuity tests on either the 1NO or 1NC path.
