Transparent rectangular auxiliary contact module with screw clamp terminals

Eaton

Eaton XTCEXFAC22 Front Auxiliary Contact 2NO/2NC 16A 500V AC

SKU CH-P8P5-DEAY1

Front-mount auxiliary contact adds two normally-open and two normally-closed circuits at 16 A, 500 V AC for XT frame B-C relays

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Front-mount auxiliary contact fits XT Frame B-C control relays
  • 16 A AC rating handles control-circuit switching duties
  • Four-pole block provides 2 NO and 2 NC contacts
  • Screw-clamp terminals give secure tool-less wiring
  • Rated for 500 V AC maximum operating voltage

Front Auxiliary Contact for XT Frame B-C

The Eaton XTCEXFAC22 is a front-mount auxiliary contact block designed for XT Frame B-C control relays. It provides four poles with two normally open and two normally closed contacts rated at 16 A and 500 V AC. This accessory suits panel builders and maintenance engineers expanding control-circuit monitoring on compatible Eaton XTRE series relays.

Check relay series and front-mount space

Verify that the target relay belongs to the XTRE control relay series and that the front mounting area is free for an additional contact block. The unit uses screw clamp terminals, so confirm that your wiring practice matches this connection type. Ensure the control circuit voltage does not exceed the 500 V AC maximum rating before installation.

Low heat and silent operation in normal use

As a passive electromechanical contact block, the device generates negligible heat and produces no audible noise during standard switching duty. Power draw is limited to the coil consumption of the host relay, with the contacts themselves adding no measurable load. The transparent housing allows visual inspection of contact status without removing the cover.

Highlights

  • Front-mount auxiliary contact fits XT Frame B-C control relays
  • 16 A AC rating handles control-circuit switching duties
  • Four-pole block provides 2 NO and 2 NC contacts
  • Screw-clamp terminals give secure tool-less wiring
  • Rated for 500 V AC maximum operating voltage

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Does the Eaton XTCEXFAC22 include mounting screws or do I need to source them separately?

The contact mounts on the front of compatible XT frame B-C devices using the integral mounting arrangement; no separate mounting hardware is included in the pack.

How do I choose between the available contact configurations for this front auxiliary contact?

This specific model provides a fixed 2NO/2NC (four-pole) arrangement rated at 16 A and 500 V AC; other contact configurations would be different part numbers.

What does the 16 A rating mean when the contact is installed in a working control circuit?

It indicates the maximum AC current each pole can continuously carry at up to 500 V AC when mounted on the front of a compatible XT series control relay.
