Compact transparent IEC contactor with screw terminals and DIN rail mounting

Eaton

Eaton XTCE007B01T 24V AC 3P 1NC 7A video accessory

SKU CH-PPH4-A8CHA

Three-pole IEC magnetic contactor with 24 V AC coil, 7 A inductive rating, one normally-closed auxiliary contact and screw terminals for DIN-rail or panel mounting

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • IEC-rated 7 A inductive switching for reliable motor control
  • 24 V AC coil enables low-voltage panel integration
  • Single normally closed auxiliary contact supports safety interlocks
  • Screw terminals and DIN-rail mounting simplify installation
  • CE, UL and CSA certifications confirm global compliance

IEC Magnetic Contactor for 24 V AC Control Circuits

The Eaton XTCE007B01T is a 3-pole, non-reversing IEC magnetic contactor designed to switch power circuits via a 24 V AC coil. It mounts on DIN rail or panel and uses screw terminals for secure wiring in industrial automation panels.

Suited for Panels Requiring a Single Normally

This contactor fits builders needing one normally closed auxiliary contact (1NC) for interlocking or status signalling within a Frame B footprint. It is not suited for applications requiring normally open auxiliary contacts, reversing operation, or a coil voltage other than 24 V AC.

7 A Inductive / 22 A Resistive Rating at 690 V AC

The decisive specification is the current rating: 7 A inductive (AC-3) and 22 A resistive (AC-1) at up to 690 V AC. Verify that your load stays within these limits before selecting this contactor.

Highlights

  • IEC-rated 7 A inductive switching for reliable motor control
  • 24 V AC coil enables low-voltage panel integration
  • Single normally closed auxiliary contact supports safety interlocks
  • Screw terminals and DIN-rail mounting simplify installation
  • CE, UL and CSA certifications confirm global compliance

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Should I pick the 7 A inductive or the 22 A resistive rating for my load?

Use the 7 A inductive rating for motors, transformers or other inductive loads; the 22 A resistive figure only applies to heating elements or similar purely resistive circuits.

What does the 24 V AC coil voltage mean when the contactor is installed in a panel?

The coil requires a 24 V AC control supply at 50 or 60 Hz; when energised it closes the three main poles and the single normally closed auxiliary contact opens.

How do the screw terminals and the 690 V AC rating limit what I can connect?

Screw terminals accept solid or stranded conductors up to the contactor's 7 A inductive / 22 A resistive capacity, and the 690 V AC maximum voltage rating sets the highest circuit voltage the main contacts may switch.
