Compact octal-base relay with rotary adjustment knob, grey enclosure, DPDT contacts, IP20 rating

Eaton

Eaton TRNP240AC Multifunction Time Delay Relay

SKU CH-XEY2-J07RP

Multifunction time delay relay with four selectable functions, 0.1 second to 600 hour range, DPDT contacts rated 10 A at 240 V AC or 30 V DC, 100 to 240 V AC/DC coil, octal socket mount

  • Four selectable timing modes cover on-delay, single-shot, flasher and voltage-controlled functions
  • Wide 100 to 240 V AC/DC input suits global control panels without extra transformers
  • 10 A DPDT contacts switch motor starters, solenoids or lighting loads directly
  • Rotary knob sets delays from .1 second to 600 hours with no programming tools
  • Standard octal socket mount and IP20 rating simplify panel installation and maintenance

Multifunction Time Delay Relay

The Eaton TRNP240AC is a multifunction time delay relay designed for industrial control panels and machinery. It suits electricians and maintenance engineers who need flexible timing logic in a single plug-in unit. The relay operates on a wide 100 to 240V AC or DC supply.

Octal Socket Installation

Installation uses a standard octal socket connection for quick panel mounting and replacement. A rotary knob sets the delay from 0.1 sec up to 600 hr across four selectable functions. Incorrect function selection or voltage mismatch are the typical wiring errors.

Four Selectable Delay Functions

The single specification that decides fit is the four selectable delay functions: flasher pause or on first, on delay, power triggered, and single shot leading edge voltage controlled. Buyers who need a different timing mode or more than four functions must choose another relay.

Highlights

  • Four selectable timing modes cover on-delay, single-shot, flasher and voltage-controlled functions
  • Wide 100 to 240 V AC/DC input suits global control panels without extra transformers
  • 10 A DPDT contacts switch motor starters, solenoids or lighting loads directly
  • Rotary knob sets delays from .1 second to 600 hours with no programming tools
  • Standard octal socket mount and IP20 rating simplify panel installation and maintenance

Specifications

BrandEATON

Questions about this item

How can I confirm the relay is timing correctly after wiring it into the socket?

Apply 100 to 240V AC to the coil, select one of the four functions with the rotary knob, and verify the DPDT contacts switch at the chosen delay between .1 sec and 600 hr.

What comes in the box and what must I source separately?

The relay itself is supplied; an octal socket for the electrical connection is not included and must be purchased separately.

Which coil voltage version should I select for a 240V AC control circuit?

The single version listed covers 100 to 240V AC, so it is suitable for a 240V AC control circuit without needing a different model.
