Rectangular rocker switch with amber indicator light and four quarter-inch tabs

Eaton

Eaton NGR15031BNA0N Lighted Rocker Switch SPST 1/4 in Tab

SKU CH-VSCQ-TJMQ9

Lighted rocker switch with SPST off/on action, 0.250 in quick-connect tabs, 10 A at 250 V AC and 15 A at 125 V AC ratings, plus a 14 V DC indicator light

  • TypeIndustrial Electrical Controls & Automation
  • Lighted indicator shows circuit status at a glance
  • 14 V DC incandescent lamp built into the rocker
  • SPST off/on action with four quick-connect tabs
  • Rated 15 A at 125 V AC and 10 A at 250 V AC
  • IP42 rated with CSA, RoHS and UL listings

Product Identity

The Eaton NGR15031BNA0N is a lighted rocker switch with an SPST contact form and four connections. It is built for control panels that need a clear visual indication of circuit status. The 14 V DC incandescent indicator light activates when the switch is in the On position. The unit carries CSA, RoHS and UL Listed certifications.

Electrical Ratings & Environment

AC contact ratings are 10 A at 250 V and 15 A at 125 V. DC contact rating is 15 A at 28 V. The IP42 rating protects against solid objects over 1 mm and dripping water. Terminals use 0.250 in quick-connect tabs for fast wiring. The switch operates with a maintained Off/On action.

Mounting & Upgrade Fit

The rectangular mounting hole measures 0.867 in by 1.734 in. This switch replaces non-illuminated SPST rockers of the same cut-out when a power-on indicator is required. It is not suitable for momentary circuits or for panels that cannot accommodate the larger rectangular opening. The quick-connect tabs also require compatible female connectors.

Highlights

  • Lighted indicator shows circuit status at a glance
  • 14 V DC incandescent lamp built into the rocker
  • SPST off/on action with four quick-connect tabs
  • Rated 15 A at 125 V AC and 10 A at 250 V AC
  • IP42 rated with CSA, RoHS and UL listings

Specifications

BrandEATON
TypeIndustrial Electrical Controls & Automation

Questions about this item

How do I mount and wire the 0.867 in x 1.734 in cut-out and 0.250 in quick-connect tabs?

Cut the panel to 0.867 in x 1.734 in, snap the switch body in, then push four 0.250 in female quick-connect terminals onto the tabs; the common mistake is reversing the two lamp terminals so the 14 V incandescent indicator never lights.

What maintenance will the 14 V incandescent indicator light require?

The indicator is a 14 V DC incandescent lamp; when it dims or fails, de-solder or unplug the two lamp tabs and replace the bulb module — the switch contacts rated 15 A at 125 V AC or 10 A at 250 V AC need no routine service.

At what load does the IP42 seal become the limiting factor during sustained use?

The IP42 rating only protects against dripping water and solid objects over 1 mm; in continuous duty the 15 A at 28 V DC or 15 A at 125 V AC contact rating will be reached before the seal degrades, so stay within those current limits.
