Eaton M22M-WKV-K10 selector switch 22 mm 2 position black
A 22 mm two-position selector switch with maintained action, 1NO contact, 60-degree knob rotation, IP67 and IP69K sealing, and 6A at 230 V AC rating
- 2-position maintained switching for reliable control
- 22 mm metal operator fits standard panel cut-outs
- IP67 and IP69K sealing protects against water and high-pressure wash-down
- NEMA 1, 2, 3, 4, 4X, 13 ratings suit harsh industrial environments
- 6 A at 230 V AC and 3 A at 24 V DC contact rating handles typical control circuits
22 mm two-position selector
The Eaton M22M-WKV-K10 is a non-illuminated selector switch with a 22 mm mounting diameter and two maintained positions. A black metal knob provides 60 degrees of rotation between settings. The operator head, bezel and basic material are all metal with a chrome bezel finish. It carries a single normally open contact block rated at 3 A at 24 V DC and 6 A at 230 V AC.
Panels needing simple on-off control
This switch suits control panels that require a maintained two-position selector with a single NO contact and high environmental sealing. It meets NEMA 1, 2, 3, 4, 4X, 13 and IP67 plus IP69K ratings for wash-down environments. Buyers who need illuminated operation, key removal, multiple contact blocks or a different contact configuration should look at other models.
Single NO contact at 230 V AC
The contact block delivers one normally open circuit rated for 6 A at 230 V AC under AC-15 duty and 3 A at 24 V DC under DC-13 duty. This single-contact arrangement determines whether the switch can drive the intended load directly or requires an interposing relay.
Highlights
- 2-position maintained switching for reliable control
- 22 mm metal operator fits standard panel cut-outs
- IP67 and IP69K sealing protects against water and high-pressure wash-down
- NEMA 1, 2, 3, 4, 4X, 13 ratings suit harsh industrial environments
- 6 A at 230 V AC and 3 A at 24 V DC contact rating handles typical control circuits
Specifications
| Brand | EATON |
|---|
Questions about this item
Will this 22 mm selector switch fit the same panel cut-out as my existing 22 mm pushbuttons?
Yes, the 22 mm mounting diameter matches standard 22 mm panel cut-outs used by most industrial pushbuttons and selector switches.
How can I verify the maintained positions are working after wiring the 1NO contact?
Rotate the black knob 60 degrees to each position; the contact should close at Position A and Position B, giving a clear tactile click at both stops.
Does the box include any mounting hardware or do I need to buy a legend plate separately?
The operator head, metal bezel and contact block are supplied; a legend plate is not included and must be purchased separately if required.
