Green illuminated push button 22 mm chrome bezel metal head

Eaton

Eaton M22M-DL-G-K20-G Illuminated Push Button 22 mm Green 2NO

SKU CH-TVX0-QWM10

22 mm illuminated momentary push button with green metal flush head, 2NO contacts rated 6 A at 230 V AC and 3 A at 24 V DC, IP66/IP67/IP69K and NEMA 1, 2, 3, 4, 4X, 13 protection

  • Engine BrandEATON
  • Engine Size22 mm
  • Green illumination for clear status indication
  • 22 mm metal flush operator with chrome die-cast bezel
  • 2NO contacts rated 6A at 230 V AC and 3A at 24 V DC
  • IP66 IP67 IP69K plus NEMA 1 2 3 4 4X 13 sealing
  • Certified to CE CSA UL CCC Bureau Veritas GOST-R Lloyd's Register

Illuminated 22 mm Push Button

The Eaton M22M-DL-G-K20-G is a momentary illuminated push button with a 22 mm green flush operator and chrome die-cast aluminum bezel. It carries a 2NO contact configuration rated at 3A at 24 DC and 6A at 230V AC. The unit meets NEMA ratings 1, 2, 3, 4, 4X, 13 and IP ratings IP66, IP67, IP69K for demanding industrial environments.

Panel Mounting and Wiring Requirements

This operator installs in a standard 22 mm panel cut-out and uses screw-clamp terminals for secure wiring. The metal head and robust bezel suit harsh conditions while the green illumination provides clear status indication. It frees up panel space by combining indication and actuation in a single 22 mm unit rated for AC-15 and DC-13 duty.

Sustained Operation in Harsh Conditions

The button maintains its NEMA and IP sealing under continuous exposure to water, dust and high-pressure washdown. Contact ratings of 3A at 24 DC and 6A at 230V AC apply to sustained loads, not just momentary peaks. Certifications from UL, CSA, CE, CCC, Bureau Veritas, GOST-R and Lloyd's Register confirm compliance for long-term industrial service.

Highlights

  • Green illumination for clear status indication
  • 22 mm metal flush operator with chrome die-cast bezel
  • 2NO contacts rated 6A at 230 V AC and 3A at 24 V DC
  • IP66 IP67 IP69K plus NEMA 1 2 3 4 4X 13 sealing
  • Certified to CE CSA UL CCC Bureau Veritas GOST-R Lloyd's Register

Specifications

Engine BrandEATON
Engine Size22 mm

Questions about this item

How long will the 230 V AC contact rating of 6 A hold up during continuous operation?

The switch is rated for 6 A at 230 V AC under the AC-15 duty class, which covers continuous electromagnetic load switching.

What heat or noise should I expect from the illuminated push button when it stays energised all day?

The unit has no moving cooling parts and draws only the LED indicator current, so it runs silent and adds negligible heat to the panel.

Which panel cut-out and mounting hardware must I already have to install this 22 mm operator?

You need a standard 22 mm panel cut-out and the matching Eaton M22 mounting nut or flange; the screw-clamp terminals accept prepared wire ends directly.
