Eaton
Eaton HT8AAGAB 30 mm push button operator 1NO/1NC green
A 30 mm flush metal push button with 1NO/1NC contacts rated 10 A at 600 V AC, NEMA 1/2/3/3R/4/4X/12/13 and IP66 protection
- TypeIndustrial Electrical Controls & Automation
- Size30 mm
- 30 mm metal flush operator fits standard panels
- Momentary 1NO/1NC contacts rated 10 A at 600 V AC
- Green anodised aluminium bezel for clear visual status
- IP66 and NEMA 1, 2, 3, 3R, 4, 4X, 12, 13 sealing
- CE, CSA and UL listed for industrial control circuits
Eaton 30 mm green push button operator
The Eaton HT8AAGAB is a 30 mm flush push button operator designed for industrial control panels. It provides momentary action with a metal head and green anodized aluminium bezel. The unit carries a 1NO/1NC contact block rated at 10 A at 600 V AC and meets NEMA A600/P600 designation.
Sealed construction and screw-clamp terminals
The operator achieves NEMA ratings 1, 2, 3, 3R, 4, 4X and 12, 13 plus IP66 ingress protection for dust-tight and wash-down environments. Connections are made through screw-clamp terminals for secure wiring. The device is CE marked and listed to UL and CSA standards.
Single 30 mm panel cut-out required
Installation requires a single 30 mm mounting hole and the operator is compatible with Allen-Bradley pushbutton panels. Buyers needing illuminated operators, different contact configurations or non-metal head materials must select an alternative part.
Highlights
- 30 mm metal flush operator fits standard panels
- Momentary 1NO/1NC contacts rated 10 A at 600 V AC
- Green anodised aluminium bezel for clear visual status
- IP66 and NEMA 1, 2, 3, 3R, 4, 4X, 12, 13 sealing
- CE, CSA and UL listed for industrial control circuits
Specifications
| Brand | Eaton |
|---|---|
| Type | Industrial Electrical Controls & Automation |
| Size | 30 mm |
Questions about this item
How is the 30 mm flush push button operator mounted in a panel cut-out?
Insert the operator through the 30 mm panel cut-out and secure it from behind using the mounting nut; the step often missed is tightening the nut to the specified torque so the bezel seals evenly against the panel surface.
Which components of the Eaton HT8AAGAB may require replacement after extended operation?
The internal contact block rated 10A at 600V AC can wear after repeated switching cycles; the metal head and anodised aluminium bezel are durable but should be inspected for corrosion if the IP66 seal is compromised.
What is the first performance limit reached during continuous high-duty use of this push button?
The contact rating of 10A at 600V AC defines the electrical limit; exceeding this current or voltage under sustained momentary action will cause contact degradation before the mechanical IP66 or NEMA 1, 12, 13, 2, 3, 3R, 4, 4X enclosure ratings are challenged.
