Transparent rectangular IEC magnetic motor starter with surface-mount base and visible terminals

Eaton

Eaton ECX09C1AAA-R63/B Nonreversing IEC Magnetic Motor Starter

SKU CH-H96A-A9WAF

IEC magnetic motor starter with electronic overload protection from 1 to 5 amps and auxiliary contacts

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Electronic overload protection with adjustable 1 A to 5 A range
  • Trip class selectable from 10A, 10, 20 or 30 for flexible motor protection
  • Three-pole IEC starter rated for 690 V AC maximum voltage
  • 120 V AC coil voltage suits standard control circuits
  • Non-reversing design with 1NO/1NC auxiliary contacts for status monitoring

IEC Motor Starter for Industrial Control

The Eaton ECX09C1AAA-R63/B is a non-reversing IEC magnetic motor starter designed for three-phase motor control in industrial automation environments. It provides electronic overload protection with adjustable current settings between 1 A and 5 A for precise equipment safeguarding.

Surface-Mount Three-Pole Integration

This starter mounts directly on a surface and occupies three poles with a 120V AC coil voltage for standard control circuit compatibility. It includes two auxiliary contacts in a 1NO/1NC configuration, freeing the control system from adding separate pilot devices for status indication.

Adjustable Overload Range Up to 5 Amps

The electronic overload relay handles trip classes 10A, 10, 20, and 30, covering a variety of motor acceleration profiles. It is rated for 3 hp at 600V AC with a maximum voltage rating of 690V AC, making it unsuitable for motors exceeding the 5 A maximum current setting or higher horsepower ratings.

Highlights

  • Electronic overload protection with adjustable 1 A to 5 A range
  • Trip class selectable from 10A, 10, 20 or 30 for flexible motor protection
  • Three-pole IEC starter rated for 690 V AC maximum voltage
  • 120 V AC coil voltage suits standard control circuits
  • Non-reversing design with 1NO/1NC auxiliary contacts for status monitoring

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

What is the highest trip class available on this starter?

The starter supports trip classes 10A, 10, 20 and 30, with 30 being the highest selectable setting.

How much heat does the coil generate when energised continuously at 120V AC?

The 120V AC coil draws modest power during continuous operation, keeping temperature rise within IEC limits for surface-mounted starters.

What control-circuit voltage must the panel already supply?

The coil requires a 120V AC control supply, so the panel must provide that voltage for the starter to operate.
