Eaton E57G-30UPN15-Q Inductive Proximity Sensor 30 mm 15 mm Range
30 mm inductive proximity sensor detects metal up to 15 mm with 10–30 V DC PNP output and IP67 stainless steel housing
- 15 mm sensing range for reliable detection
- 10 to 30 V DC supply suits common control voltages
- 500 Hz switching frequency supports fast automation cycles
- IP67 and NEMA 4X ratings withstand wash-down environments
- Stainless steel 30 mm barrel resists corrosion and impact
Cylindrical Inductive Proximity Sensor 30 mm
The Eaton E57G-30UPN15-Q is a cylindrical inductive proximity sensor with a 30 mm stainless steel housing. It operates on a 10 to 30V DC supply and provides a 3-wire PNP normally open output through a 4-pin micro DC connector. The sensing face is unshielded and rated for a maximum detecting distance of 15 mm.
Suited For Industrial Automation
This sensor suits automation engineers needing reliable metal detection in wet or dirty conditions thanks to its IP67 and NEMA 4X ratings. The operating temperature range spans -13 to 158 degrees F. It is not for applications requiring detection of non-metallic materials or sensing distances beyond 15 mm.
15 mm Unshielded Sensing Range At 500 Hz
The decisive specification is the 15 mm maximum detecting distance delivered by the unshielded coil at a 500 Hz operating frequency. This range determines whether the sensor fits the specific machine geometry and target approach speed. Verify the 15 mm reach and 100 mA load limit match your control circuit requirements before purchase.
Highlights
- 15 mm sensing range for reliable detection
- 10 to 30 V DC supply suits common control voltages
- 500 Hz switching frequency supports fast automation cycles
- IP67 and NEMA 4X ratings withstand wash-down environments
- Stainless steel 30 mm barrel resists corrosion and impact
Specifications
| Brand | EATON |
|---|
Questions about this item
What size mounting hole does the 30 mm diameter sensor need?
The sensor body is 30 mm in diameter and 71 mm long, so a 30 mm clearance hole with room for the 4-pin micro DC connector at the rear is required.
How do I wire the 3-wire PNP output to a 10-30V DC supply?
Connect brown to +10-30V DC, blue to 0 V, and black to the load; the output is normally open and switches up to 100 mA at 500 Hz.
How often should I check the IP67 and NEMA 4X seals on this stainless-steel sensor?
Inspect the connector seal and cable entry at each scheduled machine shutdown; replace the sensor if the stainless-steel housing shows corrosion or the 15 mm sensing range becomes unreliable.
