Transparent rectangular counter with six red LED digits, flush-mount bezel

Eaton

Eaton E5-496-E0401 Counter Electric LED 6 Digital 90-260VAC video accessory

SKU CH-BHQH-CY5PM

Six-digit red LED counter operates on 90-260VAC input with 24VDC output and prescaling from 0.0001 to 99.9999

  • TypeElectrical
  • ColorTransparent
  • 6-digit red LED display for clear counting
  • 90-260 VAC input suits global mains supplies
  • 24 VDC output rating for low-voltage control
  • Prescaling range 0.0001-99.9999 enables precise scaling
  • cURus and CE certified for regulated installations

Eaton E5-496-E0401 LED Counter

The Eaton E5-496-E0401 is a six-digit electrical counter with a red LED display designed for industrial counting applications. It operates on a wide input voltage range of 90-260VAC and provides a 24VDC output rating. The unit features a transparent housing and is built for flush mounting into panels or equipment enclosures. It is suited for process monitoring where precise tallying is required.

Suited for flush-mount process monitoring

This counter suits engineers and technicians needing a panel-mounted device that counts up or down at speeds up to 60000 counts per second. The prescaling range of 0.0001 to 99.9999 allows flexible measurement scaling for various sensors. It is not intended for buyers who need a portable handheld tally counter or a unit with integrated data logging and network connectivity. Applications requiring a different digit count or display colour should consider alternative models.

Verify panel cut-out and wiring before ordering

Confirm the panel cut-out matches the unit dimensions of 3.78 In length, 3.51 In width and 1.89 In depth for proper flush installation. Ensure the supply voltage falls within the 90-260VAC range and that the 6 VA power rating is compatible with the circuit. Check whether front panel push-button or remote reset wiring meets the control scheme requirements. The locking reset key feature should align with operational security needs.

Highlights

  • 6-digit red LED display for clear counting
  • 90-260 VAC input suits global mains supplies
  • 24 VDC output rating for low-voltage control
  • Prescaling range 0.0001-99.9999 enables precise scaling
  • cURus and CE certified for regulated installations

Specifications

BrandEaton
ModelE5-496-E0401
TypeElectrical
ColorTransparent

Questions about this item

What power source is required for the 90-260VAC input on the E5-496-E0401 counter?

Connect the unit to any AC supply between 90 and 260 volts; it draws 6 VA and provides a 24VDC output for external circuits.

Can the 60000 counts-per-second rate keep up with a legacy mechanical sensor?

Yes, the counter accepts up to 60000 counts per second, well above typical mechanical contact speeds, and the prescaling range 0.0001 to 99.9999 lets you match the sensor output.

How do I verify the red LED display is counting correctly after flush mounting?

Apply a known pulse source, watch the six-digit red LED increment or decrement, and use the front-panel push button or remote reset to confirm the locking reset key clears the count.
