Eaton C25DGD315A contactor, transparent enclosure, three pole non-reversing

Eaton

Eaton C25DGD315A Definite Purpose Contactor 120V AC 3 Pole Non-Reversing

SKU CH-AYKD-0J1M9

A 3-pole definite-purpose contactor rated for 15 A inductive and 20 A resistive loads at 110-120 V AC coil voltage

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • 3-pole contactor handles 15 A inductive loads
  • 20 A resistive rating supports LED lighting circuits
  • 120 V AC coil suits standard control voltage
  • Non-reversing design simplifies single-direction motor control
  • 690 V AC maximum rating fits industrial panels

Eaton 120V 3-Pole Contactor

The Eaton C25DGD315A is a definite purpose contactor built for switching lighting and motor loads in commercial and industrial panels. It operates on a 110-120V AC coil and provides three non-reversing poles rated for 690V AC maximum. The unit carries a NEMA 1 enclosure rating and a Frame Size D footprint.

For lighting and single-phase motor control

This contactor suits installers controlling LED lighting at 20 A, tungsten or fluorescent loads not rated, and single-phase motors up to 3/4 hp at 120V or 2 hp at 240V. It is not for buyers needing reversing capability, higher inductive ampacity above 15 A, or a different coil voltage.

15 A inductive full-load current

The key specification is the 15 A inductive full-load current rating, which determines whether the contactor can handle the motor or transformer inrush on your circuit. If your load exceeds this value, a larger frame or higher-rated contactor is required.

Highlights

  • 3-pole contactor handles 15 A inductive loads
  • 20 A resistive rating supports LED lighting circuits
  • 120 V AC coil suits standard control voltage
  • Non-reversing design simplifies single-direction motor control
  • 690 V AC maximum rating fits industrial panels

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

What control-circuit voltage must my system supply to operate the 120 V AC coil on this C25 contactor?

The coil is rated for 110-120 V AC, so your control circuit must deliver voltage within that range for reliable pull-in and holding.

Can I use this three-pole, non-reversing contactor in a circuit that also feeds a single-phase 240 V AC motor rated at 2 hp?

Yes, the contactor carries a 2 hp single-phase rating at 240 V AC, matching that motor load within its inductive full-load current of 15 A.

After wiring the contactor, how can I verify it is switching the load correctly?

Apply 110-120 V AC to the coil terminals and confirm the three main poles close, then measure continuity across each pole and check that the connected load (up to 20 A resistive or 15 A inductive) operates as expected.
