Eaton B100 manual motor starter with transparent toggle switch

Eaton

Eaton B100M1C Manual Motor Starter 3P 20A Toggle

SKU CH-E6JK-CS5VE

A three-pole manual motor starter rated at 20 A with toggle operation for three-phase systems up to 600 V AC

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Three-phase motor control up to 600 V AC
  • 20 A toggle operation for direct manual switching
  • NEMA size M-1 starter rated for 10 hp at 480 V
  • Single-phase ratings of 3 hp at 120 V and 7 1/2 hp at 240 V
  • Three-pole design handles 3 hp at 208 V and 240 V three-phase

Eaton B100M1C manual motor starter

The Eaton B100M1C is a NEMA Size M-1 manual motor starter rated for three-phase circuits up to 600 V AC and 20 A. It uses a toggle operator to switch three poles and is suited for controlling motors in industrial and commercial installations.

Check voltage and phase before ordering

Verify that the supply voltage matches one of the rated levels: 120 V, 208 V, 240 V, 480 V or 600 V AC. Confirm the load is three-phase and does not exceed the horsepower ratings at the corresponding voltage, and ensure the enclosure and mounting method suit the application environment.

No bundled accessories or software included

The starter ships as a standalone unit without additional components, cables or configuration software. Installation relies on the toggle operator and standard wiring practices, so no extra accessories change the setup or operation.

Highlights

  • Three-phase motor control up to 600 V AC
  • 20 A toggle operation for direct manual switching
  • NEMA size M-1 starter rated for 10 hp at 480 V
  • Single-phase ratings of 3 hp at 120 V and 7 1/2 hp at 240 V
  • Three-pole design handles 3 hp at 208 V and 240 V three-phase

Specifications

BrandEaton
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Does the B100M1C ship with any wiring, overload relays or mounting hardware included?

The starter is supplied as a single unit with a toggle operator; wiring, overload relays and mounting hardware must be sourced separately.

Which horsepower rating should I match when selecting this M-1 starter for my motor?

Choose based on your supply voltage and phase: 3 hp at 120 V single-phase, 7 1/2 hp at 240 V single-phase, 3 hp at 208 V three-phase, 3 hp at 240 V three-phase, 10 hp at 480 V three-phase or 10 hp at 600 V three-phase.

What does the 20 A current rating mean once the starter is installed in a panel?

It indicates the maximum continuous AC current the contacts can carry across all three poles at up to 600 V AC without an adjustable overload relay setting.
