Eaton NEMA magnetic motor starter transparent open frame

Eaton

Eaton AN19AN0A5E1P6 8.200 NEMA Starter Transparent

SKU CH-SE4X-2HPZT

Non-reversing NEMA magnetic motor starter with electronic overload protection adjustable from .33 to 1.65 A and 600 V AC rating

  • TypeNEMA
  • ColorTransparent
  • Non-reversing three-phase motor control
  • NEMA-rated starter handles 600 V AC
  • Electronic overload adjustable from .33 to 1.65 A
  • Selectable trip classes 10, 20, 30 for tailored protection
  • Includes one normally-open auxiliary contact for status signalling

Eaton AN19AN0A5E1P6 motor starter

The Eaton AN19AN0A5E1P6 is a non-reversing NEMA magnetic motor starter designed for three-phase motor control. It suits industrial maintenance teams and panel builders who need a Size 1 starter with electronic overload protection and surface mounting. The open design requires installation inside a suitable enclosure.

Electronic overload and auxiliary contact

The built-in electronic overload relay adjusts from .33 A to 1.65 A and offers selectable Trip Class 10, 20 or 30 settings. A single 1NO auxiliary contact is included for status signalling or interlocking with other control devices. No operator or pilot device is fitted, so any start/stop controls must be added separately.

Surface mounting and wiring considerations

The starter mounts on a flat panel using the standard NEMA Size 1 footprint. Power terminals accept conductors rated for 600 V AC; verify wire gauge against the motor full-load current. The transparent cover allows visual inspection of contact operation. Ensure the enclosure provides required clearances and environmental protection for the application.

Highlights

  • Non-reversing three-phase motor control
  • NEMA-rated starter handles 600 V AC
  • Electronic overload adjustable from .33 to 1.65 A
  • Selectable trip classes 10, 20, 30 for tailored protection
  • Includes one normally-open auxiliary contact for status signalling

Specifications

BrandEaton
ModelAN19AN0A5E1P6
TypeNEMA
ColorTransparent

Questions about this item

How often will the electronic overload relay need checking or replacement?

The electronic overload relay is adjustable from .33 A to 1.65 A with selectable trip classes of 10, 10A, 20 or 30 and includes one normally-open auxiliary contact for monitoring.

What is the continuous current limit before the starter trips?

The maximum overload relay setting is 1.65 A at 600 V AC across three poles in a non-reversing NEMA configuration.

How much heat does the starter produce when running all day?

The Freedom series NEMA starter mounts on a surface with no enclosure and uses an electronic overload relay, so heat output depends on the load current up to 1.65 A.
