Drill America DWTSR2-140 1"-40x2" OD HSS Round Adjustable Die

Threading tool for 1"-40 pipe

This Drill America round adjustable die cuts external threads on 1"-40 pipe and tubing using high-speed steel for extended wear life. The die is chamfered on both faces with a 2 to 3 thread lead on one side and a 1 to 1-1/2 thread lead on the other for threading close to a shoulder. A fine-pitch adjustment screw controls the thread fit by forcing the die sides apart or allowing them to spring together. The beveled slot permits holder-based adjustment when the screw is removed.

Compatibility checks before ordering

Verify that your workpiece material and diameter match the 1"-40 thread specification this die is designed to cut. Confirm your die stock or machine holder accepts a 2-inch outside-diameter round die and can accommodate the beveled adjustment slot. Ensure you have cutting fluid suitable for high-speed steel tooling to achieve proper thread quality and tool life. California Proposition 65 warnings apply for cancer and reproductive harm.

Adjustment mechanics and use

The fine-pitch screw provides direct control over thread class by expanding or contracting the die halves without requiring holder adjustments for basic operation. When mounted in a machine holder, removing the screw enables adjustment via the holder's own screws for faster setup changes. Dual chamfers let you start threads cleanly or work near shoulders without switching tools, reducing changeover time on multi-step jobs. High-speed steel construction resists wear during repetitive threading of steel, stainless or alloy pipe.
