Round adjustable die in silver metal finish 13/16 OD

Drill America

Drill America DWTSMR1316-5.5X.75 HSS Round Adjustable Die

SKU CH-9Y51-QCCTR

A 13/16-inch OD high-speed steel round adjustable die cuts M5.5x0.75 threads with chamfered faces for shoulder work

  • High-speed steel construction extends die life
  • 13/16 inch outer diameter fits standard holders
  • M5.5 x 0.75 metric thread cuts precise threads
  • Adjustable fine-pitch screw controls thread fit
  • Dual chamfers enable threading and shoulder work

Threading Die for M5.5 × 0.75 Threads

This High Speed Steel round adjustable die cuts M5.5 × 0.75 external threads. The 13/16 inch outside diameter fits compatible die stocks and holders. It is designed for improved wear life during threading operations on rod or pipe material.

Suitable for Mechanics Cutting Metric Threads

Machinists and maintenance technicians who need to create or repair M5.5 × 0.75 threads will find this die appropriate. Buyers requiring different thread pitches, larger diameters or non-metric standards should select another tool. The product carries a California Proposition 65 warning for chemicals known to cause cancer and reproductive harm.

Simple Installation in Standard Die Stocks

The die installs in a 13/16 inch die stock or machine holder using the integrated adjustment screw. One face offers a 2 to 3 thread chamfer for starting threads, the other a 1 to 1-1/2 thread chamfer for work near shoulders. Over-adjusting the fine-pitch screw can reduce thread accuracy or damage the die.

Highlights

  • High-speed steel construction extends die life
  • 13/16 inch outer diameter fits standard holders
  • M5.5 x 0.75 metric thread cuts precise threads
  • Adjustable fine-pitch screw controls thread fit
  • Dual chamfers enable threading and shoulder work

Specifications

BrandDRILL AMERICA

Questions about this item

What size die stock or holder accepts the 13/16" OD of this die?

The die has a 13/16 inch outside diameter, so it fits any standard die stock or machine holder made for that size.

Can the m5.5x.75 threads produced by this die mate with existing metric fasteners of the same pitch?

Yes, it cuts standard M5.5 x 0.75 threads, so they will match any correctly made M5.5 x 0.75 bolt or stud you already have.

How can I confirm the die is cutting the correct thread depth after adjustment?

Thread a known-good M5.5 x 0.75 gauge or bolt onto the new threads; smooth engagement without binding shows the die is set correctly.
