Round adjustable die, 13/16 inch OD, high speed steel, silver metal finish

Drill America

Drill America DWTSMR1316-2.3X.45 13/16" HSS Round Adjustable Die

SKU CH-997W-0BC7M

High-speed steel adjustable die cuts external threads on 13/16 inch round stock

  • 13/16" OD die cuts external threads on pipe
  • High-speed steel construction resists wear during repeated use
  • Adjustable fine-pitch screw sets precise thread fit
  • Dual chamfers handle through and shoulder threading
  • Complies with California Proposition 65 chemical disclosure

Threading Tool Specifications

This Drill America round adjustable die cuts external threads on 13/16 inch outer diameter workpieces using a 2.3 by 0.45 millimetre pitch. It is intended for machinists and maintenance technicians who require precise thread forms in steel or similar alloys.

Setup Verification

Confirm the workpiece diameter matches the 13/16 inch specification and that the material suits high speed steel tooling. Ensure the die stock or machine holder accepts a round die with chamfered faces and an adjustable split design operated by a fine pitch screw.

Sustained Cutting Behaviour

High speed steel construction provides improved wear life during extended threading cycles compared to carbon steel alternatives. The adjustable mechanism allows the die to be opened or closed to compensate for tool wear, maintaining thread accuracy over long production runs without replacing the die.

Highlights

  • 13/16" OD die cuts external threads on pipe
  • High-speed steel construction resists wear during repeated use
  • Adjustable fine-pitch screw sets precise thread fit
  • Dual chamfers handle through and shoulder threading
  • Complies with California Proposition 65 chemical disclosure

Specifications

BrandDRILL AMERICA

Questions about this item

Does the Drill America DWTSMR1316-2.3X.45 die come with a handle or holder, or must they be purchased separately?

The die is sold as the cutting tool only; a compatible die stock or machine holder must be bought separately to use it.

What thread size does the 13/16" OD HSS Round Adjustable Die with m2.3x.45 specification cut?

It cuts a metric M2.3 thread with a 0.45 mm pitch, as indicated by the m2.3x.45 marking on the die.

How does the 13/16 inch outside diameter affect the choice of holder for this die?

The 13/16 inch outside diameter determines the holder size required; you need a die stock or machine holder designed for 13/16 inch OD round dies.
