Black DJI USB 2.0 video capture dongle with RCA cable included

DJI Video Capture Card Pro+ 1080P USB 2.0 video capturing device

SKU CH-32EY-DP5JQ

Converts analogue sources like VHS, Hi8 or mini DV into 1080p digital files via USB 2.0 on Windows, Mac or Android

  • Codecsmjpeg-1920,yuv422-720
  • Formatmjpeg-1920,yuv422-720
  • Resolution Support1080P
  • Camera ResolutionUp to 1080p Video
  • ColorBlack
  • Videomjpeg-1920,yuv422-720
  • Capture analogue tapes at up to 1080p resolution
  • Driver-free setup works with Windows, macOS and Android
  • Records in MJPEG or YUV formats for editing flexibility
  • Includes RCA cable and manuals for immediate use
  • Compact 20 cm device powered entirely by USB 2.0

Capture Card Pro+ 1080P USB 2.0

The DJI Video Capture Card Pro+ is a USB 2.0 video capturing device designed to digitise analogue sources such as VHS, VCR, Hi8 and mini DV tapes. It targets users who want to preserve older recordings on Windows, Mac OS or Android systems without installing proprietary drivers.

Analogue inputs and driverless operation

The unit accepts composite RCA video and automatically detects NTSC, PAL and PAL/60 signals. Capture resolution reaches 1920x1080 in MJPEG or 720x576 in YUV422 depending on the source, and the device draws power directly from the USB 2.0 connection so no external supply is required.

System requirements and software choices

Your computer must meet the minimum specification of an Intel Pentium 4 or equivalent processor, 512 MB RAM and 100 MB free disk space. Supported operating systems include Windows XP or later, Mac OS 10.15 or later and Android 5.0 or later. Recording and streaming work with OBS, PotPlayer or QuickTime Player, but the device does not edit video.

Highlights

  • Capture analogue tapes at up to 1080p resolution
  • Driver-free setup works with Windows, macOS and Android
  • Records in MJPEG or YUV formats for editing flexibility
  • Includes RCA cable and manuals for immediate use
  • Compact 20 cm device powered entirely by USB 2.0

Specifications

BrandDJI
SeriesVideo Capture Card Pro+
ModelVideo Capture Card Pro+
Part Number1
Codecsmjpeg-1920,yuv422-720
Formatmjpeg-1920,yuv422-720
Resolution Support1080P
Camera ResolutionUp to 1080p Video
ColorBlack
Videomjpeg-1920,yuv422-720
Network Interfaceusb2.0
Software ApplicationIntel Pentium 4 or equivalent processor, 512 MB RAM, 100 MB free disk space, Windows XP or later, Mac OS 10.15 or later, Android 5.0 or later
Display1080p
CompatibilityTelevision, Camera
System RequirementsIntel Pentium 4 or equivalent processor, 512 MB RAM, 100 MB free disk space, Windows XP or later, Mac OS 10.15 or later, Android 5.0 or later
Power Supplyfalse
Dimensions20'
Sports TeamSan Francisco 49ers

Questions about this item

What resolution does the USB 2.0 interface cap the capture at in practice?

The USB 2.0 connection supports up to 1920×1080 MJPEG or 720×576 YUV capture; actual resolution depends on the analogue video source.

What cables and space does the device need to fit into my setup?

It ships with an RCA cable and measures 20 cm end to end, so allow a free USB-A port and a short run from your VCR or camcorder.

How is the card installed and what step do people miss?

Plug the USB 2.0 dongle in, connect the RCA leads to the source, then select “USB Video” and “USB Digital Audio” in OBS or QuickTime — skipping the audio source selection is the common mistake.
