DELL
DELL PowerEdge T440 5U rack server 2x Xeon Silver 4214 2.2GHz 12-core 16GB DDR4 HBA330 2x 750W PSU
A 5U tower server with 16 hot-swap 2.5-inch bays, dual 12-core Xeon Silver 4214 processors at 2.2 GHz, 16 GB DDR4 ECC memory, PERC HBA330 controller, dual Gigabit Ethernet, iDRAC 9 Express.
- TypeRack
- Rack Height5U
- Redundant Hot-swap PowerYes
- CPU TypeIntel Xeon
- CPU Speed2.2GHz (3.2GHz Turbo)
- CPU SocketLGA 3647
- Dual Xeon Silver 4214 processors deliver 24 cores at 2.2 GHz base speed
- 16 GB DDR4-2400 ECC memory installed with capacity up to 1 TB
- PERC HBA330 controller supports SAS and SATA drives across 16 hot-swap bays
- iDRAC 9 Express provides remote management with Lifecycle Controller
- Two 750 W platinum power supplies enable redundant hot-swap operation
Server system for virtualization and storage
The Dell PowerEdge T440 is a 5U rack server supplied with two Intel Xeon Silver 4214 processors running at 2.2 GHz with 3.2 GHz turbo. Each CPU provides 12 cores, giving 24 cores total for multi-threaded workloads. The system includes 16 GB of DDR4-2400 ECC registered memory across 16 slots, supporting up to 1 TB capacity.
Suited for database hosting and file services
This configuration fits environments running VMware ESXi, Hyper-V or Proxmox for virtualization, as well as SQL Server, backup targets and software-defined storage. Buyers who need installed drives, a RAID controller with cache, or a rack bezel and rails should look elsewhere, as the unit ships without drives, with an HBA controller, and without front bezel or ready rails.
HBA330 controller provides SAS and SATA connectivity
The Dell PERC HBA330 12 Gb/s storage controller manages up to sixteen 2.5-inch hot-swap bays using SAS or SATA drives. It operates in initiator-target mode without onboard RAID processing, so the host CPU handles storage logic. Dual 750 W platinum power supplies and iDRAC 9 Express complete the base platform.
Highlights
- Dual Xeon Silver 4214 processors deliver 24 cores at 2.2 GHz base speed
- 16 GB DDR4-2400 ECC memory installed with capacity up to 1 TB
- PERC HBA330 controller supports SAS and SATA drives across 16 hot-swap bays
- iDRAC 9 Express provides remote management with Lifecycle Controller
- Two 750 W platinum power supplies enable redundant hot-swap operation
Specifications
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | T440 |
| Type | Rack |
| Rack Height | 5U |
| Redundant Hot-swap Power | Yes |
| CPU Type | Intel Xeon |
| CPU Speed | 2.2GHz (3.2GHz Turbo) |
| CPU Socket | LGA 3647 |
| Number of CPU Cores | 12 Core-Processors |
| CPU Features | Silver 4214 |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 16GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1TB |
| Number of Memory Slots | 16 |
| Hard Drive (Installed) | None |
| Storage Controller | Dell Perc HBA330 Controller |
| SSD (Installed) | No |
| Raid Level | None |
| Ethernet Controller | Integrated Dell 2x1GbE Dual Port Ethernet Adapter |
| Remote Management | iDRAC9 Express |
| LAN Ports | 2 x Ports |
| Management Port | RJ 45 |
| Operating System | No |
Questions about this item
Should I pick the 2.2 GHz or 3.2 GHz figure when planning workloads?
The processors run at 2.2 GHz base and can boost to 3.2 GHz under load.
What does 16 GB DDR4 mean for actual capacity?
Two 8 GB DDR4-2400 ECC modules are installed across 16 slots, leaving room to expand toward the 1 TB maximum.
What does the HBA330 controller cap in practice?
The PERC HBA330 provides 12 Gb/s SAS and SATA connectivity for the 16 hot-swap 2.5-inch bays.
