Tall silver 5U rack server with sixteen front drive bays and dual power supplies

DELL

Dell PowerEdge T430 5U Rack Server 2x Xeon E5-2695 v4 2.1GHz 18C 32GB DDR4 HBA330 16x 2.5" 2x 750W PSU

SKU CH-XBW7-2PZ7N

5U rack server with dual 18-core Xeon processors at 2.1 GHz, 32 GB DDR4 memory, HBA330 storage controller, and sixteen 2.5-inch drive bays

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.3GHz Turbo)
  • CPU SocketLGA 2011
  • Dual Xeon E5-2695 v4 processors provide 18 cores each at 2.1 GHz base
  • 32 GB DDR4-2400 ECC memory installed with capacity up to 384 GB
  • HBA330 controller supports 16 hot-swap 2.5" SAS and SATA drive bays
  • iDRAC 8 Express enables remote server management and monitoring
  • Dual 750 W platinum power supplies deliver redundant hot-swap power

Dual 18-Core Xeon Server

The Dell PowerEdge T430 is a 5U rack server fitted with two Intel Xeon E5-2695 v4 processors. Each CPU runs at 2.1GHz with a 3.3GHz turbo frequency and provides 18 cores for multi-threaded workloads. The system ships with 32GB of DDR4 ECC registered memory installed across four modules.

Virtualisation and Storage Hosts

This server suits teams running VMware ESXi, Hyper-V or Proxmox VE clusters that need dense 2.5-inch drive capacity. The PERC HBA330 controller presents 16 hot-swap bays for SAS and SATA drives, while dual 1GbE ports and iDRAC 8 Express handle network and remote management. Buyers who require more than 384GB of memory or need PCIe Gen4 connectivity for modern accelerators should evaluate newer platforms.

16-Bay 2.5-Inch Chassis

The defining specification is the sixteen 2.5-inch hot-swap drive trays backed by a 12Gb/s SAS/SATA HBA330 controller. This bay count and controller combination determines how many disks can be attached directly without adding external enclosures or switching to a different storage protocol.

Highlights

  • Dual Xeon E5-2695 v4 processors provide 18 cores each at 2.1 GHz base
  • 32 GB DDR4-2400 ECC memory installed with capacity up to 384 GB
  • HBA330 controller supports 16 hot-swap 2.5" SAS and SATA drive bays
  • iDRAC 8 Express enables remote server management and monitoring
  • Dual 750 W platinum power supplies deliver redundant hot-swap power

Specifications

BrandDELL
SeriesPowerEdge
ModelT430
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.3GHz Turbo)
CPU SocketLGA 2011
Number of CPU Cores18 Core-Processors
CPU FeaturesE5-2695 v4
# of Processors Installed2
MAX Processors2
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc HBA330 Controller
SSD (Installed)No
Raid LevelNone
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC8 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

What comes with the server and what must I buy separately?

The chassis includes 16x 2.5" hot-swap drive trays, a PERC HBA330 12Gb/s SAS/SATA controller, dual 750W platinum PSUs, iDRAC 8 Express, dual 1GbE ports and 32GB DDR4-2400 ECC RDIMM in 4 of 12 slots. No drives, front bezel or rack rails are included.

Which memory capacity should I choose for this T430?

The system ships with 32GB across 4 DIMM slots. You can expand up to 384GB using the 8 remaining DDR4-2400 ECC registered slots. Match capacity per processor for best performance.

What does the 2.1GHz / 3.3GHz turbo rating mean in practice?

Each of the 2 Xeon E5-2695 v4 CPUs runs at 2.1GHz base with 18 cores. Under load, turbo can reach 3.3GHz depending on core count active, power and thermal headroom.
