Dell PowerEdge T430 5U tower server black chassis eight 3.5 inch drive bays front bezel

DELL

Dell PowerEdge T430 5U Rack Server 2x Xeon E5-2660 v4 2.0GHz 14-Core 32GB DDR4 8x 4TB SATA H730

SKU CH-RYM8-AXQSV

5U rack server with dual 14-core Xeon processors, 32 GB DDR4 ECC memory, PERC H730 RAID controller and eight 4 TB 7.2 K SATA drives for high-capacity storage

  • Type0
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3

Installed Memory Size 32GB

HDD 8 x 4TB 7.2K SATA

  • Dual Xeon E5-2660 v4 CPUs deliver 28 cores at 2.0 GHz base and 3.2 GHz turbo
  • 32 GB DDR4 registered ECC memory across four slots supports up to 384 GB total
  • PERC H730 1 GB controller enables RAID 0 1 5 6 10 50 60 with battery-backed cache
  • Eight 4 TB 7.2K SATA drives provide 32 TB raw capacity in 3.5 inch bays
  • iDRAC 8 Express plus dual 750 W platinum power supplies give remote management and redundant power

Dual Xeon 14-core server for office workloads

The Dell PowerEdge T430 ships with two Intel Xeon E5-2660 v4 processors, each running at 2.0 GHz with 14 cores and a 3.2 GHz turbo frequency. Thirty-two gigabytes of DDR4-2400 registered ECC memory occupy four of twelve available slots, leaving room for expansion up to 384 GB. This configuration targets small-office and remote-office deployments that need collaboration, mail, file, print or web services in a single 5U chassis.

Sustained throughput from RAID-backed storage

Eight enterprise-class 4 TB 7.2K SATA drives connect to a Dell PERC H730 controller with 1 GB cache and a battery-backed write buffer. The controller supports RAID levels 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode, allowing administrators to tune redundancy and capacity for continuous workloads. Dual-port 1 GbE Broadcom 5720 networking and iDRAC 8 Express remote management keep the system reachable during extended operations.

Redundant power and tool-less drive access

Two hot-swap 750 W platinum-rated power supplies provide N+1 redundancy, so a single unit can fail without downtime. The 3.5-inch drive bays are accessible from the front, enabling drive swaps without opening the case. A front bezel is included for physical security, while plastic mounting feet are not supplied, indicating the unit is intended for rack-mount installation.

Highlights

  • Dual Xeon E5-2660 v4 CPUs deliver 28 cores at 2.0 GHz base and 3.2 GHz turbo
  • 32 GB DDR4 registered ECC memory across four slots supports up to 384 GB total
  • PERC H730 1 GB controller enables RAID 0 1 5 6 10 50 60 with battery-backed cache
  • Eight 4 TB 7.2K SATA drives provide 32 TB raw capacity in 3.5 inch bays
  • iDRAC 8 Express plus dual 750 W platinum power supplies give remote management and redundant power

Specifications

BrandDELL
SeriesPowerEdge T430
ModelT430
Type0
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors Installed0
MAX Processors2
ChipsetIntel C610
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)8 x 4TB 7.2K SATA
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Dell Broadcom 5720 Dual Port 1GbE LOM
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much heat and power do the dual Xeon E5-2660 v4 CPUs and two 750 W platinum supplies draw when the server runs 24/7?

Each Xeon E5-2660 v4 is a 14-core 2.0 GHz chip with 3.2 GHz turbo; the system includes two 750 W platinum-efficiency hot-swap power supplies for redundant operation.

Which rails, cables or operating-system licences must I already have to install this 5U tower/rack chassis?

The 5U chassis accepts standard rack rails; it ships with a front bezel, integrated Broadcom 5720 dual-port 1 GbE LOM, iDRAC8 Express and a PERC H730 1 GB controller — no OS licence is included.

Will my existing SAS tape drive or SATA SSDs connect to the PERC H730 controller in this T430?

The H730 supports 12 Gb/s SAS and 6 Gb/s SATA with RAID 0/1/5/6/10/50/60 and pass-through, so legacy SAS tape drives and SATA SSDs are compatible.
