A silver 5U tower server with sixteen 2.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge T430 5U rack server 2x Xeon E5-2660 v4 2.0GHz 14-core 16GB DDR4 H730P 4x 960GB SSD

SKU CH-YQ8E-KRQ0H

5U rack server with dual 14-core Xeon processors at 2.0 GHz, 16 GB DDR4, H730P RAID controller and four 960 GB SATA SSDs

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.0GHz (3.2GHz Turbo)
  • CPU SocketLGA 2011
  • Dual 14-core Xeon processors reach 3.2GHz Turbo for demanding workloads
  • PERC H730P controller supports RAID 0 1 5 6 10 50 60 with 2GB cache
  • Four 960GB enterprise SSDs deliver high-capacity flash storage
  • 16GB DDR4 ECC memory expandable to 384GB across 12 slots
  • Redundant 750W platinum power supplies and iDRAC 8 Express remote management

Dual-socket Xeon server for virtualization workloads

The Dell PowerEdge T430 is a 5U rack server equipped with two Intel Xeon E5-2660 v4 processors. Each CPU provides 14 cores running at 2.0 GHz with a 3.2 GHz turbo frequency. The system ships with 16 GB of DDR4-2400 ECC registered memory across twelve slots, expandable to 384 GB. A PERC H730P controller with 2 GB cache manages four 960 GB SATA SSDs in the sixteen 2.5-inch hot-swap bays.

Redundant platinum power supplies handle thermal

Two 750 W platinum-efficiency power supplies operate in redundant hot-swap mode, delivering stable power to both processors and the full drive complement. The 5U chassis provides airflow across the dual-socket board, the H730P battery-backed cache, and the SSD array without requiring additional cooling configuration. Integrated dual-port Gigabit Ethernet and iDRAC 8 Express share the same power budget.

Battery-backed RAID controller enables data

The H730P supports RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode, allowing the four installed SSDs to be configured for redundancy or capacity. iDRAC 8 Express provides out-of-band remote management for firmware updates, power cycling and console access without an operating system. Buyers who need more than four drives or a larger memory footprint must add components separately.

Highlights

  • Dual 14-core Xeon processors reach 3.2GHz Turbo for demanding workloads
  • PERC H730P controller supports RAID 0 1 5 6 10 50 60 with 2GB cache
  • Four 960GB enterprise SSDs deliver high-capacity flash storage
  • 16GB DDR4 ECC memory expandable to 384GB across 12 slots
  • Redundant 750W platinum power supplies and iDRAC 8 Express remote management

Specifications

BrandDELL
SeriesPowerEdge
ModelT430
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.0GHz (3.2GHz Turbo)
CPU SocketLGA 2011
Number of CPU Cores14 Core-Processors
CPU FeaturesE5-2660 v4
# of Processors Installed2
MAX Processors2
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSATA
SSD (Installed)4 x 960GB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC8 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

How do I install the 14-core Xeon E5-2660 v4 processors into the LGA 2011 sockets, and which step is often missed?

Align the processor notches with the socket keys, lower gently, and close the retention lever; the step often missed is applying thermal paste before seating the heatsink.

When will the 16GB DDR4-2400 ECC registered memory need replacement or expansion?

The 12 DIMM slots support up to 384GB; add modules when workloads exceed 16GB, and replace any DIMM that reports correctable ECC errors in iDRAC logs.

What limit appears first during sustained use with the H730P controller and 960GB SATA SSDs?

The 12Gb/s SAS/SATA controller bandwidth and SSD write endurance will saturate before the dual 750W power supplies reach their thermal limit.
