Dell PowerEdge T430 5U tower server front view showing sixteen 2.5 inch drive bays

DELL

DELL PowerEdge T430 5U rack server 2× Xeon E5-2660 v4 2.0GHz 14-core 32GB DDR4 4× 960GB SSD H330

SKU CH-0ZC7-GPJ7F

A 5U rack server with dual 14-core Xeon processors at 2.0 GHz, 32 GB DDR4 ECC memory, a PERC H330 controller and four 960 GB SATA SSDs in a 16-bay chassis

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.0GHz (3.2GHz Turbo)
  • CPU SocketLGA 2011
  • Dual Xeon E5-2660 v4 14-core CPUs provide high multi-thread performance
  • 32GB DDR4-2400 ECC memory supports reliable virtualization and database workloads
  • Four 960GB SATA SSDs on PERC H330 controller deliver fast storage access
  • Sixteen 2.5" hot-swap bays allow flexible SAS, SATA or SSD capacity growth
  • Dual 750W platinum power supplies with iDRAC 8 Express ensure uptime and remote management

Dual-socket Xeon 5U tower server

This Dell PowerEdge T430 is a 5U tower server that can be converted for rack mounting. It ships with two Intel Xeon E5-2660 v4 processors, each running at 2.0 GHz with a 3.2 GHz turbo and 14 cores. The system includes 32 GB of DDR4-2400 ECC registered memory across four modules.

Suited for virtualization hosts needing dual CPUs

The dual 14-core CPUs and 16-bay 2.5-inch chassis make it a fit for virtualization, database work or file storage where core count and drive density matter. Buyers who need more than 32 GB of memory out of the box or who require more than four pre-installed SSDs should look at a different build. The single PERC H330 controller limits RAID options to the modes that card supports.

16 hot-swap 2.5-inch drive bays with H330 RAID

The chassis provides sixteen 2.5-inch hot-swap bays connected to a Dell PERC H330 12 Gb/s SAS/SATA controller. Four 960 GB SATA SSDs are already installed. Twelve DDR4 slots allow expansion up to 384 GB. Two 750 W platinum power supplies deliver redundant hot-swap power.

Highlights

  • Dual Xeon E5-2660 v4 14-core CPUs provide high multi-thread performance
  • 32GB DDR4-2400 ECC memory supports reliable virtualization and database workloads
  • Four 960GB SATA SSDs on PERC H330 controller deliver fast storage access
  • Sixteen 2.5" hot-swap bays allow flexible SAS, SATA or SSD capacity growth
  • Dual 750W platinum power supplies with iDRAC 8 Express ensure uptime and remote management

Specifications

BrandDELL
SeriesPowerEdge
ModelT430
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.0GHz (3.2GHz Turbo)
CPU SocketLGA 2011
Number of CPU Cores14 Core-Processors
CPU FeaturesE5-2660 v4
# of Processors Installed2
MAX Processors2
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H330 Controller
HDD InterfaceSATA
SSD (Installed)4 x 960GB SATA SSD
Raid LevelRAID 0/1/5/10/50
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC8 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

Should I pick the 32 GB DDR4 configuration or add more modules up to the 384 GB limit?

The system ships with 32 GB across four slots; twelve slots are available so you can expand later when workloads demand more capacity.

What does the 2.0 GHz base and 3.2 GHz turbo on the dual 14-core Xeon E5-2660 v4 mean for actual throughput?

Twenty-eight cores run at 2.0 GHz sustained and can burst to 3.2 GHz on active threads, giving strong multi-threaded performance for virtualization and databases.

How does the PERC H330 12 Gb/s SAS/SATA controller affect the four 960 GB SATA SSDs?

The H330 connects each SSD at SATA 6 Gb/s; the 12 Gb/s SAS backplane bandwidth is shared, so sequential throughput is limited by the SATA link speed.
